Installation, Operating and Servicing
Instructions
Opus 800 Gas Griddles
OG8201, OG8201/R, OG8201/C
OG8202, OG8202/R, OG8202/C
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 592 ECN 3855
Page 1 of 13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Opus 800 OG8201 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lincat Opus 800 OG8201

  • Page 1 Installation, Operating and Servicing Instructions Opus 800 Gas Griddles OG8201, OG8201/R, OG8201/C OG8202, OG8202/R, OG8202/C Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 592 ECN 3855 Page 1 of 13...
  • Page 2: Table Of Contents

    WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips.
  • Page 3: Warnings And Precautions

    WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned, and serviced by a qualified person in accordance with national and local regulations in force in the country of installation. Strip plastic coating and clean the appliance before use. During operation parts may become hot - avoid accidental contact. Parts protected by the manufacturer shall not be adjusted by the user.
  • Page 4: Checklist Of Enclosures

    CHECK LIST OF ENCLOSURES Warranty card Instructions manual Scraper Pressure regulator (NAT GAS ONLY) INSTALLATION AND COMMISSIONING This appliance must only be used by qualified professionals Site this appliance beneath an extraction canopy for the removal of combustion products. When making the gas connection, fit an isolating cock into the supply line close to the appliance for emergency shutdown or servicing purposes.
  • Page 5 Fig 1 Gas supply is at the rear of the appliance. The appliance is type ‘A’. Rooms must be ventilated in compliance with existing technical regulations. The airflow must not be less than 2 cubic metres per hour per kW of installed capacity. If the appliance must be fitted near walls, partitions kitchen furniture etc we recommend they are made from non-inflammable material, otherwise they should be covered with a suitable heat-resistant material.
  • Page 6: Operating Instructions

    Connecting to a gas supply Installation and connection to the gas supply must only be carried out by a technician authorised by your local gas supplier. Before connection, ensure that the appliance is suitable for the type of gas supplied. Ensure the gas supply is provided with an isolating cock for emergency shutdown.
  • Page 7: Cleaning

    Lighting Sequence Open the main gas cock. Depress either of the control knobs and rotate to the spark position. Depress the relevant igniter button to ignite the gas at the pilot. View the pilot flame through the viewing hole in the facia panel. When the pilot lights, keep the control knob depressed for 20 seconds and then release.
  • Page 8: Servicing, Maintenance And Component Replacement

    Chromium Plate Remove debris regularly during use. After shutdown, allow 15 minutes for the plate to partially cool. Flush with water to soften any residue. Further cool the plate. Use a fine metal bristle brush to loosen stubborn deposits. Repeat the flushing process, adding a small amount of mild detergent to the water, taking care not to let the fat drawer overflow.
  • Page 9 Place bulbs to one side, avoiding damage to the capillaries. Lift plate free from the appliance. When re-fitting the plate, ensure capillaries are routed away from the burners and do not become trapped at any point. Component Replacement Control thermostat Remove the control knobs, facia panel and raise griddle plate.
  • Page 10: Conversion

    Fit the new thermocouple and re-assemble in the reverse order. CONVERSION This appliance cannot be converted by the user. For conversion kit and instructions of how to convert contact Lincat details can be found in the service section of this manual.  UK:...
  • Page 11: Fault Finding

    FAULT FINDING Pilot will not light CHECK IGNITER FOR SPARKING CHECK GAS CHECK IGNITER LEAD SUPPLY IS ON CONNECTIONS IS GAS TYPE CORRECT CONNECT TO CORRECT GAS TYPE ADJUST AS CHECK OPERATING NECESSARY PRESSURE CHECK PILOT INJECTOR FOR CHECK GAS FLOW TO BLOCKAGE PILOT PURGE SYSTEM...
  • Page 12: Spare Parts List

    Burner will not light CHECK SUPPLY PRESSURE IS CORRECT ADJUST AS NECESSARY CHECK BURNER INJECTOR CHECK GAS FLOW TO FOR BLOCKAGE BURNER REPLACE CLEAR BLOCKAGE / THERMOSTAT REPLACE INJECTOR SPARE PARTS LIST Part Number Description Used on BU75 Burner CO113 Copper washer IG06 Igniter lead...
  • Page 13 Type number All available on serial plate  Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
