Installation, Operating and Servicing
Instructions
Opus 800 Electric Clam Griddle
OE8210, OE8211
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 607 ECN 4345
Page 1 of 12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lincat Opus 800 OE8210
Summary of Contents for Lincat Opus 800 OE8210
- Page 1 Installation, Operating and Servicing Instructions Opus 800 Electric Clam Griddle OE8210, OE8211 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 607 ECN 4345 Page 1 of 12...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned and serviced by a qualified person in accordance with national and local regulations in force in the country of installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person. -
Page 4: Installation And Commissioning
INSTALLATION AND COMMISSIONING This product is heavy; prior to installation a handling assessment should be made. This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. Means of isolation with at least 3mm contact separation in all poles must be incorporated into the fixed wiring of this appliance. - Page 5 Fig 1 IS 607 ECN 4345 Page 5 of 12...
-
Page 6: Operating Instructions
OPERATING INSTRUCTIONS Griddle plate preparation Before using the appliance for the first time, wipe off protective oil from the griddle plates and wash down with a warm detergent solution. Griddle plate (stainless steel): Coat with a light film of cooking oil Clam plate (Aluminium): Fit the Teflon sheets to the clam plate before cooking. -
Page 7: Cleaning
Your Lincat product has a manufacturer’s warranty. This requires you to maintain and care for your product and follow maintenance instructions. If you fail to maintain your unit or damage components Lincat may charge you for a warranty repair. Please check the website for terms and conditions. -
Page 8: Servicing, Maintenance And Component Replacement
dry. Cover with new or cleaned Teflon sheet. Do not use a scraper or abrasive cleaners on the aluminium plate. SERVICING, MAINTENANCE AND COMPONENT REPLACEMENT All servicing, maintenance and component replacement on this appliance should be carried out by one of our recommended service engineers. Neon replacement Remove the screws beneath the facia panel, and remove the facia panel by rotating the bottom forward. - Page 9 Remove the bracket and remove the stat. Remove the control knob and the screws holding the thermostat to the clam facia. Fit new thermostat by reversal of the above procedure. Do not damage the capillary. Ensure the stat bracket in not in direct contact with any part of the element sheath. Element Replacement On the griddle plate: Remove the screws beneath the facia panel, and remove the facia panel by rotating...
-
Page 10: Fault Finding
FAULT FINDING Please refer to the Service Help Desk number on the final page of this manual. SPARE PARTS LIST Part Number Description EL306 Element Handle – clam top HA05 Control knob – clam top KN245 Control knob – griddle KN509 LE38 NE46... - Page 11 All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
- Page 12 Damage due to incorrect installation, modification, unauthorised service work or damage due to scale, food debris build-up, etc. The manufacturer disclaims any liability for incidental, or consequential damages. Attendance is based on reasonable access to the appliance to allow the authorised technician to carry out the warranty work.
