Installation, Operating and Servicing
Instructions
Opus 700 Electric Griddles
OE7205, OE7206, OE7209
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 193 ECN 3607
Page 1 of 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Opus 700 OE7205 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lincat Opus 700 OE7205

  • Page 1 Installation, Operating and Servicing Instructions Opus 700 Electric Griddles OE7205, OE7206, OE7209 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 193 ECN 3607 Page 1 of 10...
  • Page 2: Table Of Contents

    WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips.
  • Page 3: Warnings And Precautions

    WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned and serviced by a qualified person in accordance with national and local regulations in force in the country of installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person.
  • Page 4: Installation And Commissioning

    INSTALLATION AND COMMISSIONING This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. If replacing the plug connect the terminals as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Install this appliance on a level surface ensuring all vents are unobstructed.
  • Page 5: Operating Instructions

    Means of isolation with at least 3mm contact separation in all poles must be incorporated into the fixed wiring of this appliance. The fixed wiring insulation must be protected by insulated sleeving having a temperature rating of at least 60 Deg Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57) Connection of the electrical supply cable is at the rear of the appliance.
  • Page 6: Cleaning

    Fig 2 Turn on the power supply, the green neon (A) will illuminate indicating power to the appliance. The cooking area is separated into two heat zones. Knob (B) controls the LH zone, knob (D) the RH zone. On the OE7205 the zones are split 50%-50%, on the OE7206 and OE7209 the zones are split 60% LH and 40% RH.
  • Page 7: Servicing, Maintenance And Component Replacement

    Rinse away all traces of detergent and dry plate. Protect with a light coating of cooking oil. For heavy deposits, a de-greasing agent ‘Carbon-Off’ is available from Lincat. General cleaning Clean all panels with warm water and mild detergent, do not use abrasive materials or cleaners containing chlorine.
  • Page 8: Fault Finding

    Remove the element and fit the replacement, locating carefully in the cartridge. Reposition the cartridge beneath the griddle plate and tighten up the cartridge strap. Rewire the new element including earth tag. Refit the facia. Thermostat replacement Remove the relevant control knob. Remove the facia panel as above. Disconnect the cables from the faulty thermostat;...
  • Page 9: Accessories

    ACCESSORIES Part Number Description Used on OA7905 Floor stand OE7205 OA7914 Floor stand OE7206, OE7209 OA7906 Splashguard OE7205 OA7916 Splashguard OE7206, OE7209 Fig 3 To fit the appliance to the floor stand proceed as follows: Measure the spacing between the legs of the appliance front to back. Remove the legs.
  • Page 10: Service Information And Guarantee

    Type number All available on serial plate  Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.

This manual is also suitable for:

Opus 700 oe7209Opus 700 oe7206
