Installation; Mounting Height & Clearance - Zephyr Siena Pro ZSP-E36BS Use, Care And Installation Manual

C
n .
m i
x . D
m a
3 6
Standard
Hood Heights Duct Cover
minimum (A) 27-1/2"
maximum (B) 42"
Ceiling Heights
minimum (C) 87-1/2" (7' 3-1/2") 105" (8' 9")
maximum (D) 112" (9' 4" )
DUCTING
A minimum of 10" round duct is recommended to
Always use rigid type metal ducts only. Flexible
ALWAYS, when possible, reduce the number of
transitions and turns. If a long duct run is required,
increase duct size from 10" to 12".
If turns or transitions are required: Install as far
away from opening and as far apart, between 2,
A
n .
as possible.
m i
x . B
m a
Minimum mount height between range top to hood
bottom should be no less than 24".
i n .
Maximum mount height should be no higher than
a x .
" m
2 4
34".
" m
3 4
It is important to install the hood at the proper
mounting height. Hoods mounted too low could
mounted too high will be hard to reach and will
"
If available, also refer to range manufacturer's
height clearance requirements and recommended
Extension
Duct Cover
heights up to 12 feet. Turn to page 11 for part
45"
78"
number and ordering information.
148" (12' 4")
DAMAGE-SHIPMENT / INSTALLATION:
• Please fully inspect unit for damage before

installation.

• If the unit is damaged in shipment, return the
unit to the store in which it was bought for
repair or replacement.
• If the unit is damaged by the customer, repair
or replacement is the responsibility of the
customer.
be made by arrangement between customer
and installer.
6
www.zephyronline.com
