Panasonic TH-37PR10U Service Manual

Specifications
Power Source
Power Consumption
Power on
Stand-by condition
Power off condition
Plasma Display panel
Screen size
(No. of pixels)
Operating condition
Temperature
Humidity
Applicable signals
Scanning format
PC signals
Connection terminals
PC IN
High Definition Hospitality Plasma Display
120 V AC, 50/60Hz
340 W (37 inch)
Save OFF 0.7 W, Save ON 0.5 W (37 inch)
0.2 W (37 inch)
Drive method: AC type 37-inch,
16:9 aspect ratio (37 inch)
32.2" (819 mm) (W) × 18.0" (457 mm) (H) × 37" (938 mm) (diagonal) (37 inch)
36.3" (922 mm) (W) × 20.4" (518 mm) (H) × 42" (1,057 mm) (diagonal) (42 inch)
737,280 (1,024 (W) × 720(H)) (37 inch)
[3,072 × 720 dots] (37 inch)
32 °F - 104 °F (0 °C - 40 °C)
20% - 80%
525 (480) / 60i 60p, 625 (575) / 50i
30p 24sF.... SMPTE274M, 1250 (1080) / 50i
VGA, SVGA
XGA, SXGA, UXGA..... (compressed) (37 inch)
Horizontal scanning frequency 15 - 110 kHz
(37 inch)
Vertical scanning frequency 48 - 120 Hz (37 inch)
(HIGH-DENSITY MINI-D-SUB 15PIN)
AUDIO IN (M3 JACK)
TH-37PR10U
TH-42PR10U
GPH10D Chassis
380 W (42 inch)
Save OFF 0.7 W, Save ON 0.5 W (42 inch)
0.2 W (42 inch)
Drive method: AC type 42-inch,
16:9 aspect ratio (42 inch)
786,432 (1,024 (W) × 768(H)) (42 inch)
[3,072 × 768 dots] (42 inch)
50p, 750 (720) / 60p 50p, 1125 (1080) / 60i
VGA, SVGA, XGA
SXGA, UXGA..... (compressed) (42 inch)
Horizontal scanning frequency 15 - 110 kHz
(42 inch)
Vertical scanning frequency 48 - 120 Hz (42 inch)
Y or G with / sync 1.0 Vp-p (75-ohm)
Y or G without / sync 0.7 Vp-p (75-ohm)
B / P :0.7 Vp-p (75-ohm)
B / CB
R / P :0.7 Vp-p (75-ohm)
R / CR
HD / VD :1.0 - 5.0 Vp-p (high impedance)
0.5 Vrms (high impedance)
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights reserved.
distribution is a violation of law.
ORDER NO. MTNC070411CE
D34 Canada: D10
50i 24p 25p
Unauthorized copying and
