PG701WU/PG706WU/PG706HD
Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product
in a safe manner, as well as registering your product for future service. Warranty information contained in this
User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website. "Antes de operar su equipo lea cu idadosamente las instrucciones en este manual"
Model No. VS17687/VS17693/VS17692
Model Name: PG701WU/PG706WU/PG706HD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PG701WU and is the answer not in the manual?

Questions and answers

Related Manuals for ViewSonic PG701WU

Summary of Contents for ViewSonic PG701WU

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
  • Page 2 At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well. Once again, thank you for choosing ViewSonic®!

  • Page 3: Safety Precautions - General

    Safety Precautions - General Please read the following Safety Precautions before you start using the projector. • Keep this user guide in a safe place for later reference. • Read all warnings and follow all instructions. • Allow at least 20“ (50 cm) clearance around the projector to ensure proper ventilation.
  • Page 4 (UPS). • If smoke, an abnormal noise, or a strange odor is present, immediately switch the projector off and call your dealer or ViewSonic®. It is dangerous to continue using the projector. • Use only attachments/accessories specified by the manufacturer.
  • Page 5 Safety Precautions - Ceiling Mounting Please read the following Safety Precautions before you start using the projector. If you intend to mount the projector on the ceiling, we strongly recommend that you use a proper fitting projector ceiling mount kit and that you ensure it is securely and safely installed.

  • Page 6: Table Of Contents

    Replacing the Remote Control Batteries ..............15 Initial Setup ............... 16 Choosing a Location ....................16 Projection Dimensions ..................17 PG701WU/PG706WU .................... 17 16:10 Image on a 16:10 Screen ................... 17 16:10 Image on a 4:3 Screen ..................18 PG706HD ....................... 19 16:9 Image on a 16:9 Screen ..................
  • Page 7 Making Connections ..........27 Connecting to Power ....................27 Connecting to Video Sources ................28 HDMI Connection ....................28 S-Video Connection ....................29 Composite Video Connection ................30 Connecting to Computer Sources .................31 VGA Connection ....................31 VGA Out Connection ..................... 31 Connecting to Audio .....................32 Operation ..............
  • Page 8 Menu Functions ............49 General On-Screen Display (OSD) Menu Operation ..........49 On-Screen Display (OSD) Menu Tree ..............50 DISPLAY Menu ......................55 IMAGE Menu ......................58 POWER MANAGEMENT Menu ................62 BASIC Menu ......................65 ADVANCED Menu ....................67 SYSTEM Menu .......................72 INFORMATION Menu ...................74 Specifications ......................75 Appendix ..............
  • Page 9 Lamp Information ....................95 Lamp Hour ......................95 Extending Lamp Life ....................95 Lamp Replacement Timing ..................96 Replacing the Lamp ....................96 Regulatory and Service Information ......97 Compliance Information ..................97 FCC Compliance Statement ................... 97 Industry Canada Statement ................... 97 CE Conformity for European Countries ..............

  • Page 10: Features

    Introduction The PG7 series is a high brightness projector series that produces the finest of details regardless of the amount of ambient light in the environment. The PG7 series can also fit in any small-to-medium sized space, such as meeting rooms or classrooms.

  • Page 11: Product Overview

    Product Overview Projector Controls and Functions Temperature Indicator Light Power Indicator Lamp Indicator Light Light MENU BLANK EXIT ENTER COLOR SOURCE MODE Vent (heated air Focus Ring exhaust) Zoom Ring Projection Lens Remote IR sensor Description Toggles the projector between standby mode and Power On. Power Manually corrects distorted images resulting from an angled ] Keystone Keys...

  • Page 12: Connection Ports

    Connection Ports 9 10 PG706WU/PG706HD PG701WU Security Slot AC Power Cord Inlet Ceiling Mount Holes Security Bar Adjuster Foot Port Description [1] AUDIO OUT Audio signal output socket. [2] AUDIO IN Audio signal input socket. [3] HDMI 1 HDMI port.

  • Page 13: Remote Control

    Button Description Manually corrects distorted images resulting from an Controls and Functions Keystone Keys angled projection. Enter Enacts the selected OSD PG701WU Menu item. Selects the desired Left/ Right menu items and makes Down adjustments. Menu Turns on/off the On-Screen Display (OSD) Menu or goes back to previous OSD Menu.
  • Page 14 PG706WU/PG706HD Button Description Selects the desired menu Left/ Right items and makes adjustments. Down Menu Turns on/off the On-Screen Display (OSD) Menu or goes back to previous OSD Menu. Emits visible laser pointer light (Laser) for presentation purposes. Exit Exits and saves menu settings.

  • Page 15: Remote Control Effective Range

    Remote Control Tffective Range To ensure proper function of the remote control follow the steps below: The remote control must be held at an angle within 30° perpendicular to the projector’s IR remote control sensor(s). The distance between the remote control and the sensor(s) should not exceed 8 m (26 ft.) NOTT: Refer to the illustration for the location of...

  • Page 16: Initial Setup

    Initial Setup This section provides detailed instructions for setting up your projector. Choosing a Location Personal preference and room layout will decide the installation location. Consider the following: • Size and Position of your screen. • Location of a suitable power outlet. •...

  • Page 17: Projection Dimensions

    Projection Dimensions NOTT: See “Specifications” on page 75 for the native display resolution of this projector. PG701WU/PG706WU • 16:10 Image on a 16:10 Screen • 16:10 Image on a 4:3 Screen NOTT: (e) = Screen / (f) = Center of Lens...

  • Page 18: 16:10 Image On A 4:3 Screen

    16:10 Image on a 4:3 Screen (a) Screen (b) Projection Distance (c) Image (d) Vertical Offset Size minimum maximum Height minimum maximum 1524 1828 2011 1778 2133 2346 2032 2438 2681 1016 2286 2742 3017 1143 2540 3047 3352 1270 2794 3352 3687...

  • Page 19: 16:9 Image On A 16:9 Screen

    PG706HD • 16:9 Image on a 16:9 Screen • 16:9 Image on a 4:3 Screen NOTT: (e) = Screen / (f) = Center of Lens 16:9 Image on a 16:9 Screen (a) Screen (b) Projection Distance (c) Image (d) Vertical Offset Size minimum maximum...

  • Page 20: 16:9 Image On A 4:3 Screen

    16:9 Image on a 4:3 Screen (a) Screen (b) Projection Distance (c) Image (d) Vertical Offset Size minimum maximum Height minimum maximum 1524 1832 2015 1778 2137 2351 2032 2443 2687 2286 2748 3023 1029 2540 3053 3358 1143 2794 3358 3694 1257...

  • Page 21: Mounting The Projector

    If you buy a third-party mount, please use the correct screw size. Screw size can vary depending on the thickness of the mounting plate. To ensure the most secure installation, please use a ViewSonic® wall or ceiling mount. 2. Ensure the screws used to attach a mount to the projector meet the following specifications: •...

  • Page 22: Preventing Unauthorized Use

    Preventing Unauthorized Use The projector has several built-in security features to prevent theft, access, or accidental setting changes. Using the Security Slot To help prevent the projector from being stolen, use a security slot locking device to secure the projector to a fixed object. Below is an example of setting up a security slot locking device: NOTT: The security slot can also be used as a safety anchor if the projector is...

  • Page 23: Using The Password Function

    Using the Password Function To help prevent unauthorized access or use, the projector offers a password security option. The password can be set through the On-Screen Display (OSD) Menu. NOTT: Make note of your password, and keep it in a safe place. Setting a Password Press Menu to open the OSD Menu and go to: SYSTTM...

  • Page 24: Changing The Password

    Changing the Password Press Menu to open the OSD Menu and go to: SYSTTM > Security Settings > Change Password. 2. Press Tnter, the message, ‘INPUT CURRENT PASSWORD’ will appear. 3. Enter the old password. ͫ If the password is correct, the message, ‘INPUT NEW PASSWORD’ will appear.

  • Page 25: Forgetting The Password

    Forgetting the Password If the password function is activated, you will be asked to enter the six-digit password every time you turn on the projector. If you enter the wrong password, the password error message, as pictured to the right, will appear for 5 seconds, and the message ‘INPUT PASSWORD’...

  • Page 26: Locking The Control Keys

    Locking the Control Keys With the control keys on the projector locked, you can prevent your settings from being changed accidentally (by children, for example). NOTT: When the Panel Key Lock is On, no control keys on the projector will operate except Power.

  • Page 27: Making Connections

    Making Connections This section guides you on how to connect the projector with other equipment. Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the projector. 2. Plug the power cord into a power outlet. NOTT: When installing the projector, incorporate a readily accessible disconnect device in the fixed wiring, or connect the power plug to an easily accessible...

  • Page 28: Connecting To Video Sources

    Connecting to Video Sources HDMI Connection Connect one end of an HDMI cable to the HDMI port of your video device. Then connect the other end of the cable to the HDMI 1 or HDMI 2 port of your projector. PG706WU/PG706HD PG701WU...

  • Page 29: S-Video Connection

    S-Video Connection Connect one end of an S-Video cable to the S-Video port of your video device. Then connect the other end of the cable to the S-VIDTO port of your projector. PG706WU/PG706HD...

  • Page 30: Composite Video Connection

    Composite Video Connection Connect one end of a Video cable to the Video port of your video device. Then connect the other end of the cable to the VIDTO port of your projector. PG706WU/PG706HD...

  • Page 31: Connecting To Computer Sources

    VGA Out Connection After establishing the VGA Connection, connect one end of a VGA cable to the VGA port of your monitor. Then connect the other end of the cable to the MONITOR OUT port of your projector. PG706WU/PG706HD PG701WU...

  • Page 32: Connecting To Audio

    Connecting to Audio The projector is equipped with speakers, however, you can also connect external speakers to the AUDIO OUT port of the projector. NOTT: The audio output is controlled by the projector’s Volume and Mute settings.

  • Page 33: Operation

    Operation Turning the Projector On/Off Starting Up the Projector 1. Press the Power button to turn on the projector. 2. The lamp will light up, and a “Power On/Off Ring Tone” will play. 3. The Power Indicator Light stays green when the projector is On. NOTT: •...

  • Page 34: Shutting Down The Projector

    Shutting Down the Projector 1. Press the Power or Off button and a confirmation message will appear to prompt you to press the Power or Off button a second time. Additionally you can press any other button to cancel. NOTT: If you do not respond in a few seconds after the first press, the message will disappear.

  • Page 35: Selecting An Input Source

    Selecting an Input Source The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. If you want the projector to automatically search for the input source, ensure the Quick Auto Search function in the SYSTTM menu is On.

  • Page 36: Adjusting The Projected Image

    Adjusting the Projected Image Adjusting the Projector's Height and Projection Angle The projector is equipped with one (1) adjuster foot. Adjusting the foot will change the projector’s height and the vertical projection angle. Carefully adjust the feet to fine tune the projected image’s position. Auto-Adjusting the Image Sometimes, you may need to improve the picture quality.

  • Page 37: Correcting Keystone

    Correcting Keystone Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection. To correct this, besides adjusting the height of the projector, you may also: 1. Use the keystone keys on the projector or remote control to display the keystone page.

  • Page 38: Hiding The Image

    Hiding the Image In order to draw the audience’s full attention to the presenter, you can press Blank on the projector or remote control to hide the screen image. Press any key on the projector or remote control to restore the image. CAUTION: Do not block the projection lens as this could cause the blocking object to become heated and deformed or even cause a fire.

  • Page 39: Controlling The Projector Through A Lan Environment

    Controlling the Projector through a LAN Tnvironment NOTT: This function is only available on the PG706WU/PG706HD. The projector supports Crestron® software. With correct settings for the LAN Control Settings menu, you can manage the projector from a computer using a web browser when the computer and the projector are properly connected to the same local area network.
  • Page 40 NOTT: • If the Projector IP Address still does not appear, contact your network administrator. • If the RJ45 cables are not properly connected, the Projector IP Address, Subnet Mask, Default Gateway and DNS Server settings will display 0.0.0.0. Make sure the cables are properly connected and perform the procedures above again.

  • Page 41: Controlling The Projector Through A Web Browser

    Controlling the Projector through a Web Browser Once you have the correct IP address for the projector and the projector is on or in standby mode, you can use any computer that is on the same local area network to control the projector.
  • Page 42 1. Enter the address of the projector in the address bar of your browser and press Enter. The main page of the Network Control will appear. NOTT: Accessing the Network Settings, Email Alert page, or Projector/LAN Firmware Update page requires the Administrator’s password. The default password is “0000”.
  • Page 43 4. The Crestron (e-Control)® page displays the Crestron e-Control user interface. 5. Projector Firmware Update i. Visit ViewSonic’s website to download the Projector Software Update Firmware by LAN: https://www.viewsonic.com. ii. Upload the Projector Firmware file to the Network Control website.
  • Page 44 NOTT: If the download process fails, please refer to the “Projector Software Update Firmware by USB” below. Visit ViewSonic’s website to download the Projector Software Update https://www.viewsonic.com Firmware : Connect the USB A cable to the projector and computer. Continuously press the projector’s Power Key and...

  • Page 45: About Crestron E-Control

    About Crestron e-Control® 1. The Crestron e-Control® page provides a variety of virtual keys to control the projector or adjust the projected pictures. You can press reveal more buttons. i. These buttons function the same as the ones on the OSD menus or remote control.
  • Page 46 i. This section is only used with the Crestron Control System. Please contact Creston or refer to its user manual for setup information. ii. You can name the projector, keep track of its location and the person in charge of it. iii.
  • Page 47 3. The Info page displays the information and status of the projector. Press “Exit” to go back to the Remote Network Operation page. 4. After selecting the “Contact IT Help”, the HELP DESK window will appear in the upper right corner of the screen. You will be able to deliver messages to RoomView™...

  • Page 48: Pjlink™, Snmp, Amx And Xpanel Formats Supported

    Crestron RoomView On the “Edit Room” page, enter the IP Address (or hostname) as shown on the projector’s on-screen display (OSD) menu, and “02” for IPID, “41794” for the reserved Crestron control port. Please go to the below website to get the RoomView™ User Guide and more information: http://www.crestron.com/products/roomview_connected_embedded_ projectors_devices/resources.asp...

  • Page 49: Menu Functions

    Menu Functions This section will introduce the On-Screen Display (OSD) Menu and its options. General On-Screen Display (OSD) Menu Operation NOTT: The OSD screenshots in this manual are for reference only and may differ from the actual design. Some of the following OSD settings may not be available. Please refer to the actual OSD of your projector.

  • Page 50: On-Screen Display (Osd) Menu Tree

    On-Screen Display (OSD) Menu Tree Main Menu Sub-menu Menu Option DISPLAY Aspect Ratio Auto 16:9 16:10 Native Keystone -40~40 Lens Shift -20~20 (PG706HD only) Position X: -5 ~ 5, Y: - 5 ~ 5 Phase 0~31 H. Size -15~15 Zoom 0.8X ~2.0X OverScan Off/1/2/3/4/5...
  • Page 51 Main Menu Sub-menu Menu Option IMAGT Advanced Color -50~50 Tint (PG706WU/ -50~50 PG706HD only) Sharpness 0~31 Gamma 1.8/2.0/2.2/2.35/ 2.5/Cubic/sRGB Brilliantcolor Off/1/2/3/4/ 5/6/7/8/9/10 Noise Reduction 0~31 Color Management Primary Color Saturation Gain Reset Color Settings Reset Cancel Auto Power On Signal Disable/VGA/HDMI/ Disable/Enable Direct Power On...
  • Page 52 Sound Reminder Off/On Start Counting/Off Pattern Test Card Blank Timer Disable/5 min/10 min/15 min/20 min/25 min/30 Message Splash Screen Black Blue ViewSonic ADVANCTD 3D Settings 3D Sync Auto Frame Sequential Frame Packing Top-Bottom Side-by-Side 3D Sync Invert Disable/Invert Save 3D Settings...
  • Page 53 Main Menu Sub-menu Menu Option ADVANCTD LAN Control Settings LAN Settings DHCP ON/Static IP (PG706WU/ Projector IP Address PG706HD only) Subnet Mask Default Gateway DNS Server Standby LAN Control Off/On Apply Lamp Settings Lamp Mode Normal/Eco/ Dynamic Eco/ SuperEco+ Reset Lamp Hours Reset/Cancel Lamp Hours Information Lamp Usage Time...
  • Page 54 Main Menu Sub-menu Menu Option SYSTTM High Altitude Mode Quick Auto Search Security Settings Change Password Power On Lock Off/On Panel Key Lock Remote Control Code 1/2/3/4/5/6/7/8 Control Method RS-232 Baud Rate 2400/4800/9600/14400/19200/38400/57600/115 INFORMATION Source Color Mode Resolution Color System IP address (PG706WU/PG706HD only) MAC address...

  • Page 55: Display Menu

    DISPLAY Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the DISPLAY menu. Then press Tnter or use to access the DISPLAY menu. 3. Press to select the menu option. Then press Tnter to display its sub-menu, or press...
  • Page 56 Menu Option Description Aspect Ratio Auto Scales an image proportionally to fit the projector’s native resolution in its horizontal width. This is suitable for the incoming image which is neither in 4:3 nor 16:9 and you want to make most use of the screen without altering the image’s aspect ratio.
  • Page 57 Menu Option Description Phase Adjusts the clock phase to reduce image distortion. NOTT: This function is only available when a PC input signal is selected. H. Size Adjusts the horizontal width of the image. NOTT: This function is only available when a PC input signal is selected.

  • Page 58: Image Menu

    IMAGT Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the IMAGT menu. Then press Tnter or use to access the IMAGT menu. 3. Press to select the menu option. Then press to display its sub-menu, Tnter or press...
  • Page 59 Menu Option Description Color Mode Brightest Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms. Presentation Designed for presentations under daylight environment to match PC and notebook coloring.
  • Page 60 Menu Option Description Color Temp. 8000K Images appear bluish white. 6500K Images maintain a normal white appearance. 5500K Images appear reddish white. To set a custom color temperature, you can further adjust the following items: Red Gain/Green Gain/Blue Gain Adjusts the Contrast levels of Red, Green, and Blue. Red Offset/Green Offset/Blue Offset Adjusts the Brightness levels of Red, Green, and Blue.
  • Page 61 Menu Option Description Advanced Noise Reduction This function reduces electrical image noise caused by different media players. The higher the setting, the less the noise. (Not available when input signal is HDMI.) Color Management Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered.

  • Page 62: Power Management Menu

    POWTR MANAGTMTNT Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the POWTR MANAGTMTNT menu. Then press Tnter or use to access the POWTR MANAGTMTNT menu. 3. Press to select the menu option. Then press Tnter to display its sub-menu, or press...
  • Page 63 Menu Option Description Auto Power On Signal Selecting VGA/HDMI allows the projector to turn on automatically once the VGA/HDMI signal is fed through the VGA/HDMI cable. You can also select All and the projector will turn on automatically upon receiving either a VGA or HDMI signal.
  • Page 64 Menu Option Description Standby Settings The functions below are available in standby mode (plugged in, but not turned on). VGA Loop Through When selecting On, the projector outputs the signal received only from COMPUTER IN. Audio Pass Through When selecting On, the projector outputs an audio signal when the Audio In and Audio Out sockets are correctly connected to a proper device.

  • Page 65: Basic Menu

    BASIC Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the BASIC menu. Then press Tnter or use to access the BASIC menu. 3. Press Tnter to select the menu option. Then press to display its sub-menu, or press to adjust/select the setting.
  • Page 66 Menu Option Description Presentation Timer Presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Timer Period Sets the time period. If the timer is already on, the timer will restart whenever the Timer Period is reset.

  • Page 67: Advanced Menu

    ADVANCTD Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the ADVANCTD menu. Then press Tnter or use access the ADVANCTD menu. 3. Press to select the menu option. Then press to display its sub-menu, Tnter or press to adjust/select the setting.
  • Page 68 Menu Option Description 3D Settings This projector features a 3D function which enables you to enjoy 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view 3D images. 3D Sync The default setting is Auto and the projector automatically chooses an appropriate 3D format when detecting 3D...
  • Page 69 Menu Option Description LAN Control Settings LAN Settings ͫ DHCP ON: Select this if you are in a DHCP environment (PG706WU/PG706HD and Projector IP Address, Subnet Mask, Default Gateway, only) DNS Server settings will be automatically retrieved. ͫ Static IP: Select this if you are in a non-DHCP environment and make adjustments to below settings.
  • Page 70 Lamp Mode ͫ Normal: Provides full lamp brightness. ͫ Eco: Reduces lamp power consumption by 20% (PG701WU)/30% (PG706WU/PG706HD) and lowers brightness to extend the lamp life and decreases the fan noise. ͫ Dynamic Eco: Reduces lamp power consumption by up to 30% (PG701WU)/65% (PG706WU/PG706HD) depending on the content brightness level.
  • Page 71 Menu Option Description Closed Caption Closed Caption Enable Activates the function when the selected input signal carries (PG706WU/PG706HD closed captions. only) NOTT: • Captions: An on-screen display of the dialogue, narration, and sound effects of TV programs and videos that are closed captioned (usually marked as “CC”...

  • Page 72: System Menu

    SYSTTM Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the SYSTTM menu. Then press Tnter or use to access the SYSTTM menu. 3. Press to select the menu option. Then press to display its sub-menu, Tnter or press...
  • Page 73 Menu Option Description High Altitude Mode We recommend you use the High Altitude Mode when your environment is between 1,500 m to 3,000 m above sea level, and ambient temperature is between 5°C–25°C. NOTT: • Do not use High Altitude Mode if your environment is between 0 to 1,499 m, and the temperature is between 5°C to 35°C.

  • Page 74: Information Menu

    INFORMATION Menu 1. Press the Menu button to display the On-Screen Display (OSD) Menu. 2. Press to select the INFORMATION menu and display its contents. Menu Option Description Source Shows the current input source. Color Mode Shows the selected mode in the IMAGE menu. Resolution Shows the native resolution of the input source.

  • Page 75: Specifications

    (12.3” x 4.3” x 8.7”) Weight Physical 3.7 kg (8.16 lbs) 3.95 kg (8.71 lbs) Power Saving 300W (Typical) 310W (Typical) Modes < 0.5W (Standby) Please use the power adapter from ViewSonic® or an authorized source only. The test condition follows EEI standards.

  • Page 76: Projector Dimensions

    Projector Dimensions 312 mm (W) x 108.37 mm (H) x 221.8 mm (D) 312 mm 108.37 221.8 MENU BLANK EXIT 62.72 mm 91.81 mm ENTER COLOR SOURCE MODE Timing Chart Analog RGB Resolution Mode Refresh Clock 3D Sync rate (Hz) frequency (MHz) Frame Sequential Top-Bottom Side-by-Side...
  • Page 77 Resolution Mode Refresh Clock 3D Sync rate (Hz) frequency (MHz) Frame Sequential Top-Bottom Side-by-Side (kHz) 1280 x 800 WXGA_60 59.81 49.702 83.5 Supported Supported Supported WXGA_75 74.934 62.795 106.5 WXGA_85 84.88 71.554 122.5 WXGA_120 (Reduce 119.909 101.563 146.25 Supported Blanking) 1280 x 1024 SXGA_60 60.02...

  • Page 78: Hdmi (Pc)

    HDMI (PC) Resolution Mode Refresh Clock 3D Sync rate (Hz) frequency (MHz) Frame Sequential Top-Bottom Side-by-Side (kHz) 640 x 480 VGA_60 59.94 31.469 25.175 Supported Supported Supported VGA_72 72.809 37.861 31.5 VGA_75 37.5 31.5 VGA_85 85.008 43.269 720 x 400 720 x 400_70 70.087 31.469...

  • Page 79: Hdmi (Video)

    Resolution Mode Refresh Clock 3D Sync rate (Hz) frequency (MHz) Frame Sequential Top-Bottom Side-by-Side (kHz) 1680 x 1050 1680x1050_60 59.954 65.29 146.25 Supported Supported 640 x 480@67Hz MAC13 66.667 30.24 832 x 624@75Hz MAC16 74.546 49.722 57.28 1024 x 768@75Hz MAC19 74.93 60.241...

  • Page 80: Ir Control Table

    IR Control Table Format Byte 1 Byte 2 Byte 3 Byte 4 NEC-F2 NEC-F2 COMP NEC-F2 HDMI/HDMI 1 NEC-F2 HDMI 2 NEC-F2 Auto Sync NEC-F2 Source NEC-F2 NEC-F2 NEC-F2 Left Enter NEC-F2 NEC-F2 Right NEC-F2 Down/ Menu NEC-F2 NEC-F2 (INFORMATION) Exit NEC-F2 Aspect...

  • Page 81: Address Code

    Format Byte 1 Byte 2 Byte 3 Byte 4 (Presentation Timer) VIDEO Address Code Code 1 83F4 Code 2 93F4 Code 3 A3F4 Code 4 B3F4 Code 5 C3F4 Code 6 D3F4 Code 7 E3F4 Code 8 F3F4...

  • Page 82: Rs-232 Command Table

    Write Blue 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x01 0x68 Splash Screen Write ViewSonic 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x02 0x69 Splash Screen Read Status 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x0A 0x68...
  • Page 83 Function Type Action Command Light source Mode Write SuperEco+ 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x10 0x03 0x70 Light source Mode Read Status 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x10 0x6E Message Write 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x27 0x00 0x84 Message Write 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x27 0x01 0x85...
  • Page 84 Function Type Action Command Vertical position Write Shift Down 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x07 0x01 0x66 Vertical position Read Get Value 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x12 0x07 0x66 Color temperature Write 5500K 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x08 0x00 0x66 Color temperature Write 6500K 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x08 0x01 0x67...
  • Page 85 Function Type Action Command Blank Write 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x09 0x01 0x68 Blank Write 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x09 0x00 0x67 Blank Read Status 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x12 0x09 0x68 Keystone-Vertical Write Decrease 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x0A 0x00 0x68...
  • Page 86 Function Type Action Command Source input Write D-Sub/Comp. 1 0x06 0x14 0x00 0x04 0x00 0x34 0x13 0x01 0x00 0x60 Source input Write D-Sub/Comp. 2 0x06 0x14 0x00 0x04 0x00 0x34 0x13 0x01 0x08 0x68 Source input Write HDMI 1 0x06 0x14 0x00 0x04 0x00 0x34 0x13 0x01 0x03 0x63 Source input Write HDMI 2...
  • Page 87 Function Type Action Command Language Write Greek 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x16 0x77 Language Read Status 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x15 0x00 0x62 Light Source Usage Write Reset to ZERO 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x01 0x00 0x62 Time Light Source Usage Read...
  • Page 88 Function Type Action Command Remote Control Write code 6 0x06 0x14 0x00 0x04 0x00 0x34 0x0C 0x48 0x05 0xA5 Code Remote Control Write code 7 0x06 0x14 0x00 0x04 0x00 0x34 0x0C 0x48 0x06 0xA6 Code Remote Control Write code 8 0x06 0x14 0x00 0x04 0x00 0x34 0x0C 0x48 0x07 0xA7 Code Remote Control...

  • Page 89: Glossary

    Glossary This section describes the standard glossary of terms used in projector models. All terms are listed in alphabetical order. NOTT: Some terms may not be applicable to your projector. Aspect Ratio Refers to the ratio of the image width to the image height. Auto Sync Built-in intelligent auto adjustment function that will re-adjust the frequency and clock values to provide the best picture quality.
  • Page 90 Activating it will improve projector cooling and performance. INFORMATION Displays the timing mode (video signal input), the projector model number, the serial number, and the ViewSonic® website URL. Input Select Toggles between the various input options that are available for the...
  • Page 91 Keystone The distortion of an image caused by projecting it onto an angled surface. It can be adjusted vertically via the ] Keystone Keys. Lamp Settings The projector’s lamp information and settings can be viewed and adjusted by viewing the “Lamp Hours Information” or adjusting the “Lamp Mode”. Lens Shift The projector’s lens can be shifted vertically by adjusting the “Lens Shift”...

  • Page 92: Troubleshooting

    Zoom Ring Manually adjust the size of the projected image. Troubleshooting Common Problems This section describes some common problems that you may experience when using the projector. Problem Possible Solutions The projector does not turn on • Ensure the power cord is properly attached to the projector and to the power outlet.

  • Page 93: Led Indicators

    LTD Indicators Light Status and Description Power Green Stand-by mode Flashing Green Powering up Green Normal operation Green Normal power-down cooling Flashing Downloading Green Green Green Burn in off Lamp Green First light source-lit error cooling Flashing Light source error in normal operation Green Color wheel start has failed Heating/Cooling...

  • Page 94: Maintenance

    • ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the lens or case. Some chemical cleaners have been reported to damage the lens and/or case of the projector. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.

  • Page 95: Lamp Information

    Reduces lamp power consumption by 20% (PG701WU)/30% (PG706WU/PG706HD) and lowers brightness, and decreases fan noise. Dynamic Tco Reduces lamp power consumption by up to 30% (PG701WU)/65% (PG706WU/PG706HD) depending on the content's brightness level. SuperTco+ Reduces lamp power consumption by 60% and lowers brightness to extend the lamp life and decreases the fan noise.

  • Page 96: Lamp Replacement Timing

    Lamp Replacement Timing When the Lamp Indicator Light lights up, please install a new lamp or consult your dealer. CAUTION: An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. Replacing the Lamp It is recommended to turn the power off and disconnect the projector from the power outlet, and contact a qualified service personnel for lamp replacement.

  • Page 97: Regulatory And Service Information

    Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 98: Declaration Of Rohs2 Compliance

    The following information is only for TU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law.

  • Page 99: Indian Restriction Of Hazardous Substances

    Schedule 2 of the Rule. Product Disposal at Tnd of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®...

  • Page 100: Copyright Information

    Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic® and the three birds logo are registered trademarks of ViewSonic® Corporation. VESA is a registered trademark of the Video Electronics Standards Association.

  • Page 101: Customer Service

    For technical support or product service, see the table below or contact your reseller. NOTT: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn 香港 (繁體中文) www.viewsonic.com/hk/ Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/...

  • Page 102: Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
  • Page 103 (e) the serial number of the product. 3. Take or ship the product freight prepaid in the original container to an authorized ViewSonic service center or ViewSonic. 4. For additional information or the name of the nearest ViewSonic service center, contact ViewSonic. Limitation of implied warranties:...
  • Page 104 Txclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.

  • Page 105: Mexico Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
  • Page 106 Txclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based...
  • Page 107 Tel: (52) 999-925-1916 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com FOR USA SUPPORT: Tijuana: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 14035 Pipeline Ave. Chino, CA 91710, USA Col 20 de Noviembre Tel: 800-688-6688 Tijuana, Mexico E-Mail: http://www.viewsonic.com Projector Mexico Warranty Term Template In UG...
