4. Analog front-end for DSP (Digital Signal Processing) Connect any analog source to the Evo
PhonoDAC Two analog input to digitize its signal and send it to a computer for digital signal
processing. Connect the Evo PhonoDAC Two analog output to an amplifier.
You can also connect the Evo PhonoDAC Two between a preamplifier and a power amplifier or in
DSP include: equalizing, DRC (Digital Room Correction), filtering, speaker response compensation.
5. Increase performance. Add the Evo Clock Two: your files will sound clearer and more focussed,
with richer details. Vinyl playback and rip will be more accurate. A proprietary connection between
Evo PhonoDAC Two and Evo Clock Two allows for automatic clock management. Please note that
the S/PDIF input is not available when the Evo Clock Two is used.
6. Maximize performance. Add the Evo Supply Two to power both Evo PhonoDAC Two and Evo
Clock Two with stable, clean energy. Your music files will sound like never before. Of course, the
Evo PhonoDAC Two will take advantage of the Evo Supply Two even when the Evo Clock Two is
the processor loop or tape loop of an integrated amplifier.
M2TECH
EVO P DAC Two
HONO
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP
M2TECH
EVO P DAC Two
HONO
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP
M2TECH
FREQUENCY SELECT
EVO CLOCK TWO
DOWN UP
PRECISION CLOCK GENERATOR
M2TECH
EVO P DAC Two
HONO
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP
M2TECH
FREQUENCY SELECT
EVO CLOCK TWO
DOWN UP
PRECISION CLOCK GENERATOR
M2TECH
OUTPUTS
POWER ON
EVO SUPPLY TWO
LOW NOISE POWER SUPPLY
not used.
