- Page 1 CT06 HYDRAULIC CRIMPING TOOL USER MANUAL Safety, Operation and Maintenance © 2014 STANLEY Black & Decker, Inc. New Britain, CT 06053 U.S.A. 58543 4/2019 Ver. 8...
-
Page 3: Table Of Contents
REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN AUTHORIZED AND CERTIFIED DEALER. For the nearest certified dealer, call STANLEY Infrastructure at (503) 659-5660 and ask for a Customer Service Representative. CT06 User Manual ◄ 3... -
Page 4: Safety Symbols
Always observe safety symbols. They are included for your safety and for the protection of the tool. LOCAL SAFETY REGULATIONS Enter any local safety regulations here. Keep these instructions in an area accessible to the operator and maintenance personnel. 4 ► CT06 User Manual... - Page 5 Do not inspect space provided in this manual. or clean the tool while the hydraulic power source is The CT06 Hydraulic Crimping Tool will provide safe and connected. Accidental engagement of the tool can dependable service if operated in accordance with the cause serious injury.
-
Page 6: Tool Stickers & Tags
TOOL STICKERS & TAGS 76651 CT06 1650 PSI Combined Sticker NOTE: D A N G E R D A N G E R THE INFORMATION LISTED ON THE STICKERS SHOWN, MUST BE LEGIBLE AT ALL FAILURE TO USE HYDRAULIC HOSE LABELED AND CER- DO NOT LIFT OR CARRY TOOL BY THE HOSES. -
Page 7: Hose Types
This hose is not certifi ed non-conductive and must never be used near electrical conductors. HOSE SAFETY TAGS To help ensure your safety, the following DANGER tags are attached to all hose purchased from STANLEY. DO NOT REMOVE THESE TAGS. -
Page 8: Hose Recommendations
HOSE RECOMMENDATIONS 8 ► CT06 User Manual... -
Page 9: Htma / Ehtma Requirements
2000 psi 2000 psi (At the power supply outlet) (172 bar) (138 bar) (138 bar) (138 bar) (138 bar) Note: These are general hydraulic system requirements. See tool specifi cation page for tool specifi c requirements. CT06 User Manual ◄ 9... -
Page 10: Operation
LATCH NIB REPLACEMENT 7. Periodically verify the crimping force of the tool. Refer to “Die Load Verification” on page 11. The CT06 Hydraulic Crimping Tool has two main components in the 4-point compression head: SETUP AND TEST •... - Page 11 The relief valve on a universal pressure CT can be 3. Position the test slug within the nibs. adjusted to increase or decrease the tool’s crimping 4. Actuate the tool to squeeze the test slug. force. Standard CT’s do not have a relief valve. CT06 User Manual ◄ 11...
- Page 12 4. Wipe the tool thoroughly with a clean, dry cloth. 3. Move the hydraulic system control valve to the ON position. 5. Clean any foreign matter or joint compound from the die holder surfaces. 12 ► CT06 User Manual...
- Page 13 STORAGE Replace any damaged or missing safety labels and tags before storing the tool. Clean, dry and lubricate moving parts before storage. Store in a clean, dry place. CT06 User Manual ◄ 13...
-
Page 14: Tool Protection & Care
This can cause damage to internal seals. • Always replace hoses, couplings and other parts with replacement parts recommended by STANLEY. Supply hoses must have a minimum working pressure rating of 2500 psi/172 bar. 14 ► CT06 User Manual... -
Page 15: Troubleshooting
Connect output (return) line to OUT port. Excessive back-pressure. If back-pressure is greater than 250 psi/17 bar, clear the return line obstruction or restriction. Trigger guard bent and binding on Repair or replace trigger assembly. spool in bore. CT06 User Manual ◄ 15... -
Page 16: Specifications
Optimum Flow ..........................8 GPM / 30 LPM Porting ................................-8 SAE Hose Whips & Couplers ............................No Weight ..............................13 lbs / 5.9 kg Overall Length ..........................20 inches / 50.8 cm Overall Width ..........................7.25 inches / 18 cm 16 ► CT06 User Manual... -
Page 17: Ct06 Parts Illustration
CT06 PARTS ILLUSTRATION CT06 User Manual ◄ 17... -
Page 18: Ct06 Parts List
TRIGGER GUARD 51183 TRIGGER 52534 SETSCREW 58439 ADAPTER 58440 RETAINING RING 58441 SLEEVE 58442 OIL TUBE 76651 COMBINED CT06 1650 PSI STICKER 58520 CYLINDER 58521 PISTON 58522 CYLINDER HEAD 58523 T-SEAL ■ 58525 PUSH ROD 58594 RETAINER RING 67259 CHECK VALVE ASSY... - Page 20 STANLEY Infrastructure 6430 SE Lake Road Portland, Oregon 97222 USA (503) 659-5660 / Fax (503) 652-1780 www.stanleyinfrastructure.com...
