PT-45-KFA / PT-80T-KFA / PT-140T-KFA / PT-175T-KFA / PT-215T-KFA
Locating Your Serial Number:
Your serial number can be found on a white label on the right side cover of your heater. For Example:
150812779. Have your Serial Number ready before calling customer service at 800-641-6996.
DANGER
the instructions and warnings provided with this heater. Failure to comply can result in fire or
explosion that can cause property loss, bodily injury, or loss of life. Only persons who can follow
and understand these instructions should operate or service this heater. If you need heater info;
such as an operating manual, labels, etcetera, contact Pinnacle Climate Technologies at 800-641-
6996.
DANGER
OF ADEQUATELY VENTILATED BUILDINGS OR STRUCTURES UNDER CONSTRUCTION,
ALTERATION OR REPAIR. This is an unvented portable heater that uses air (Oxygen) from within
the area in which it is used. Failure to provide adequate combustion and ventilation air will result
in asphyxiation, carbon monoxide poisoning, bodily injury or death. Refer to "Ventilation" on Page
6.
FACTORY ID: 001
MODEL NUMBERS:
CONSUMER: READ AND SAVE THESE INSTRUCTIONS
GENERAL HAZARD WARNING: READ AND UNDERSTAND ALL OF
THE INSTRUCTIONS IN THIS MANUAL BEFORE ASSEMBLING,
STARTING, OR SERVICING THE HEATER. Be sure to comply with
NOT FOR USE IN RESIDENTIAL LIVING AREAS OR IN ENCLOSED
SPACES WITHOUT ADEQUATE VENTILATION. FOR OUTDOOR USE.
INDOOR USE PERMITTED ONLY FOR: THE TEMPORARY HEATING
KEROSENE FORCED AIR
®
1 Industrial Blvd #101, Sauk Rapids, MN 56379 USA • Toll Free (800) 641-6996
Fax: 320-251-2922 • Web: www.protemp.us • Email: info@pinnacleclimate.com
HEATER
User's Manual &
Operating Instructions
© 2018 Pinnacle Climate Technologies, Inc.
PTKC-406
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Protemp PT-45-KFA
Summary of Contents for Protemp PT-45-KFA
- Page 1 ® Operating Instructions MODEL NUMBERS: PT-45-KFA / PT-80T-KFA / PT-140T-KFA / PT-175T-KFA / PT-215T-KFA CONSUMER: READ AND SAVE THESE INSTRUCTIONS Locating Your Serial Number: Your serial number can be found on a white label on the right side cover of your heater. For Example: 150812779.
-
Page 2: Table Of Contents
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® TABLE OF CONTENTS Safety Information.........2-3 Maintenance..........8-9 What’s in the Box..........4 Wiring Diagrams..........10 Specifications..........5 Troubleshooting Guide........11 Features............5 Exploded View..........12 Assembly Instructions........5 Parts List............13 Operation............6-7 Limited Warranty..........14 SAFETY INFORMATION FIRE, BURN, INHALATION AND EXPLOSION HAZARD. -
Page 3: Safety Information
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® SAFETY INFORMATION (CONT.) WARNING RISK OF INDOOR WARNING RISK OF ELECTRIC AIR POLLUTION! SHOCK! The products described in this manual are kerosene ALWAYS use only the electrical power (voltage and frequency) specified on the model plate of the heater. -
Page 4: What's In The Box
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® WHAT’S IN THE BOX (45-KFA / 80T-KFA) Cord Wraps (Optional) Carry Handle (1) Shown With Optional Cord Wraps Heater (1) 10 mm Screws (2) 15 mm Screws (2) WHAT’S IN THE BOX (140T-KFA / 175T-KFA / 215T-KFA) Tip: Be sure to remove the axle from the side of the Styrofoam packaging. -
Page 5: Specifications
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® SPECIFICATIONS Model # 45-KFA 80T-KFA 140T-KFA 175T-KFA 215T-KFA Rating: Btu/Hr / kW 45,000 / 13.2 80,000 / 23.4 140,000 / 41.03 175,000 / 51.3 215,000 / 63.01 Fuel Consumption: Gal/Hr / L/Hr 0.35 / 1.32 0.63 / 2.38... -
Page 6: Operation
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® OPERATION NOTE: Kerosene should only be stored in a blue Fueling The Heater: container that is clearly marked “Kerosene.” Never Kerosene (K-1) store kerosene in a red container. Red is associated For optimal performance of this heater, it is strongly with gasoline. - Page 7 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® OPERATION (CONT.) Starting the Heater: (Ignition) Stopping / Restarting Heater: 1. Fill the tank with kerosene or other approved fuel - To stop the heater, move the power switch to the “Off” until needle on fuel gauge points to “F”.
-
Page 8: Maintenance
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® MAINTENANCE Service: ROTOR: The rotor with carbon vanes should be evaluated DO NOT TAMPER WITH THE UNIT. HAVE A COMPETENT every heating season. The rotor is behind the air filters. SERVICEMAN MAKE ANY NECESSARY ADJUSTMENT OR The vanes should be inspected for damage or wear. - Page 9 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® MAINTENANCE (CONT.) Service (Continued): PUMP PRESSURE: While heater is operating, turn adjusting screw SPARK PLUG: clockwise to increase, counter-clockwise to decrease Clean and re-gap every 600 hours of operation, or pressure.
-
Page 10: Wiring Diagrams
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® WIRING DIAGRAMS 45-KFA 80T - 215T-KFA 80T-KFA 140T-KFA / 175T-KFA / 190T-KFA (80T-KFA) (140T-KFA) (175T-KFA / 190T-KFA / 215T-KFA) Models 140T/175T/190T/215T-KFA have a digital display. © 2018 Pinnacle Climate Technologies, Inc. Kerosene Forced Air Heater User’s Manual... -
Page 11: Troubleshooting Guide
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® TROUBLESHOOTING GUIDE Problem Possible Cause Solution Heater Ignites, but main PCB shuts off Incorrect pump pressure. Adjust pump pressure. after a short period of time. Dirty input, output or lint filter. Clean / replace air or lint filter. -
Page 12: Exploded View
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® EXPLODED VIEW 33** 34** 40** 35** 37** 36** 43** * 45-KFA - 80T-KFA Only 38** ** 140T-KFA - 215T-KFA Only 42** © 2018 Pinnacle Climate Technologies, Inc. Kerosene Forced Air Heater User’s Manual... -
Page 13: Parts List
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® PARTS LIST Description 45-KFA 80T-KFA 140T-KFA 175T-KFA 215T-KFA Drain Bolt – – 70-002-0115 70-002-0115 70-002-0115 Fuel Gauge 70-007-0110 70-007-0110 70-007-0215 70-007-0215 70-007-0215 Fuel Filter 70-003-0100 70-003-0100 70-003-0200 70-003-0200 70-003-0200... -
Page 14: Limited Warranty
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® LIMITED WARRANTY Pinnacle Climate Technologies, Inc. warrants this heater to normal operating condition, or not defective the item will be the original retail purchaser only, to be free from defects in returned freight collect.
