PT-40-GFA-EU / PT-60V-GFA-EU / PT-100V-GFA-EU / PT-150V-GFA-EU
CONSUMER: READ AND SAVE THESE INSTRUCTIONS
GENERAL HAZARD WARNING:
DANGER
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH
THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS
OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN. ASPHYXIATION, CARBON
MONOXIDE POISONING AND / OR ELECTRIC SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE
OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS
MANUAL, LABEL, ETC. CONTACT THE MANUFACTURER.
FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID
WARNING
COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER OR
CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY
THESE INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR MAY
CONTAIN VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE,
SOLVENTS, PAINT THINNERS, DUST PARTICLES OR UNKNOWN CHEMICALS.
Model Numbers
© 2017 Obelis S.A Registered Address:
Bd. Général Wahis, 53, 1030 Brussels, Belgium
User's Manual &
Operating Instructions
®
PEGA-400
Advertisement
Table of Contents
Related Manuals for Protemp PT-40-GFA-EU
Summary of Contents for Protemp PT-40-GFA-EU
-
Page 1: Operating Instructions
User’s Manual & Operating Instructions ® Model Numbers PT-40-GFA-EU / PT-60V-GFA-EU / PT-100V-GFA-EU / PT-150V-GFA-EU CONSUMER: READ AND SAVE THESE INSTRUCTIONS GENERAL HAZARD WARNING: DANGER FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN. -
Page 2: Table Of Contents
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Table Of Contents Safety Information..........1-3 Wiring Diagram............9 Specifications and Features........4 Troubleshooting Guide........10 Operation............5-7 Exploded View...........11 Ventilation............8 Parts List............12 Maintenance............8 Safety Information NOT FOR HOME OR RECREATIONAL VEHICLE USE. -
Page 3: Safety Information
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Safety Information RISK OF INDOOR AIR PROPANE, BUTANE AND LPG WARNING DANGER POLLUTION! ARE EXPLOSIVE GASES! WHAT TO DO IF THE SMELL OF GAS IS PRESENT: The products described in this manual are –... - Page 4 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Safety Information The hose assembly shall be WARNING RISK OF ELECTRIC SHOCK! WARNING pro tected from traffic, building ALWAYS use the electrical power (voltage and material, contact with hot surfaces, and frequency) specified on the model plate of the heater.
-
Page 5: Specifications
The gas pressure regulator CAUTION 2. Remove all items from carton and hose assembly supplied with the heater must be used without alteration. Specifications Model # PT-40-GFA-EU PT-60V-GFA-EU PT-100V-GFA-EU PT-150V-GFA-EU 12.3 17.6 19.8-28.4 32.5-43.9 Fuel Consumption (g/hr) 1,200 1,500-2,000... -
Page 6: Specifications And Features
– Flammable, explosive under pressure, heavier I3B/P(50) G30 Butane at 50 mbar / G30 than air and pools in low areas. PT-40-GFA-EU I3P(30) / G31 G31 Propane at 30 mbar NL, RO, TR I3P(37) / G31 G31 Propane at 37 mbar GB, FR, PT, IE –... - Page 7 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Plug Replacement RISK OF ELECTRIC SHOCK! DISCONNECT FROM POWER BEFORE MAINTENANCE. WARNING NOTE: This section only applies to heaters sold or used in Great Britain. This appliance is supplied with a BS1363 3 pin The blue wire must be connected to the terminal plug fitted with a fuse.
- Page 8 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Operation Pre-Lighting Instructions: – Fasten full gas tank and connect proper fitting Connecting the Gas Cylinder to gas cylinder valve by turning COUNTER- CLOCKWISE.
-
Page 9: Lighting Instructions
(page 5). Ignition Ignition PT-40-GFA-EU PT-60V-GFA-EU / PT-100V-GFA-EU / Valve Knob PT-150V-GFA-EU Valve Knob Figure 5 © 2017, Obelis S.A. Gas Forced Air Heater User’s Manual... -
Page 10: Ventilation
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Ventilation CARBON MONOXIDE POISONING MAY LEAD TO DEATH! DANGER – Risk of indoor air pollution and Carbon Monoxide Poisoning. Use heater only in Minimum Ventilation Opening Needed well ventilated areas. -
Page 11: Wiring Diagram
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Wiring Diagram PT-40-GFA-EU / PT-60V-GFA-EU / PT-100V-GFA-EU / PT-150V-GFA-EU Figure 7 © 2017, Obelis S.A. Gas Forced Air Heater User’s Manual... -
Page 12: Troubleshooting Guide
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Troubleshooting Guide Problem Possible Cause(s) Solution 1. No electric power to heater. 1. Check current at outlet. If voltage is correct, inspect extension and power cords for cuts, frays or breaks Fan does not turn when... -
Page 13: Exploded View
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Exploded View Figure 8 © 2017, Obelis S.A. Gas Forced Air Heater User’s Manual... -
Page 14: Parts List
NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE Parts List PT-40-GFA-EU / PT-60V-GFA-EU / PT-100V-GFA-EU / PT-150V-GFA-EU Outer Shell Inner Shell Handle Motor Rear Guard Multi Bracket High Limit Switch... - Page 15 NEVER LEAVE HEATER UNATTENDED WHILE BURNING, CONNECTED TO A POWER SOURCE, OR WHILE ® CONNECTED TO A FUEL SOURCE _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________...
- Page 16 Manufactured by: Pinnacle Climate Technologies, Inc. Sauk Rapids, MN 56379 USA © 2017 Obelis S.A Registered Address: Bd. Général Wahis, 53, 1030 Brussels, Belgium...
