TABLE OF CONTENTS

General Safety Instructions
Introduction
Specifications
Major Components
Operating Instructions
Strap Joint Formation & Appearance
Adjustments
Parts List
Troubleshooting
Changing Strap Sizes
Tool Options
Declaration Of Conformity

INTRODUCTION

The SCM is a light weight, manually operated hand tool intended for use with Apex and Magnus
strapping. The tool is easy to load, tension and seal.
Once the strap has been placed around the package, the operator puts both layers of strap into
the tool, lowers the feed wheel, removes any strap slack and tensions the strap. The keyed
sealless joint is then created and the strap is cut free of the supply.
This manual provides the information necessary for the operation of the SCM hand tool and lists
all of the parts in the event maintenance is needed. Therefore, it is valuable and should be saved.
Extra care should be taken in performing maintenance on the SCM since fasteners and other small
components used on this tool are a combination of SAE and metric sizes.
Page
2
4
Signode tools and machines are designed
5
and warranted to work together with
Signode strapping and seals. Use of non-
5
Signode strap, seals and/or manufactured
or specified replacement parts may result
6
in strap breakage or joint separation while
applying strapping to a load or during
8
normal shipping and handling. This could
result in severe personal injury.
9
10
13
16
18
19
