- Page 1 Grandstream Networks, Inc. GWN7610/GWN7600/GWN7600LR Wireless Access Points User Manual GWN7600LR GWN7610 GWN7600 Outdoor Long Range 802.11ac Enterprise 802.11ac Mid-Tier 802.11ac Wave-2 Wave-2 WiFi Access point WiFi Access Point WiFi Access Point...
- Page 2 Grandstream Networks, Inc. is not permitted. The latest electronic version of this guide is available for download here: http://www.grandstream.com/support Grandstream is a registered trademark and Grandstream logo is trademark of Grandstream Networks, Inc. in the United States, Europe and other countries. CAUTION Changes or modifications to this product not expressly approved by Grandstream, or operation of this product in any way other than as detailed by this guide, could void your manufacturer warranty.
- Page 3 Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
- Page 4 GNU GPL INFORMATION GWN7610/GWN7600/GWN7600LR firmware contains third-party software licensed under the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License (GPL) for the exact terms and conditions of the license.
-
Page 5: Table Of Contents
Firmware Version 1.0.1.31 ......................17 Firmware Version 1.0.1.27 ......................17 WELCOME ........................18 PRODUCT OVERVIEW ....................20 Technical Specifications ......................... 20 INSTALLATION ......................25 Equipment Packaging ........................25 GWN7610/GWN7600/GWN7600LR Access Point Ports ..............27 P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... - Page 6 LED Patterns ..........................32 Discover the GWN7610/GWN7600/GWN7600LR ................33 Method1: Discover the GWN7610/GWN7600/GWN7600LR using its MAC address ....33 Method 2: Discover the GWN7610/GWN7600/GWN7600LR using GWN Discovery Tool ..34 Use the Web GUI .......................... 34 Access Web GUI ........................35 WEB GUI Languages ......................
- Page 7 Maintenance ..........................80 Basic ............................80 Upgrade ..........................81 Access ........................... 82 Syslog ............................ 83 Logserver ..........................83 Debug ............................84 Capture (GWN7610/GWN7600 Only)..................84 Core Files ..........................87 Ping/Traceroute ........................87 P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
- Page 8 Provisioning and Backup ......................100 Download Configuration......................100 Upload Configuration ......................100 Configuration Server ......................101 Reset and reboot ......................... 101 Syslog ............................101 EXPERIENCING THE GWN76XX WIRELESS ACCESS POINTS ......102 P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
- Page 9 Table of Tables Table 1: GWN7610 Technical Specifications ..................20 Table 2: GWN7600 Technical Specifications ..................21 Table 3: GWN7600LR Technical Specifications ..................23 Table 4: GWN7610/GWN7600 Equipment Packaging ................25 Table 5: GWN7600LR Equipment Packaging ..................26 Table 6: GWN7610/GWN7600 Ports Description .................. 27 Table 7: GWN7600LR Ports Description ....................
- Page 10 Figure 12: GWN7600LR Vertical Mounting ................... 31 Figure 13: GWN7600LR Horizontal Mounting ..................31 Figure 14: Discover the GWN7610/GWN7600/GWN7600LR using its MAC Address ......33 Figure 15: GWN Discovery Tool ......................34 Figure 16: GWN7610/GWN7600/GWN7600LR Web GUI Login Page ..........35 Figure 17: Change Password on First Boot ..................
- Page 11 Figure 66: Schedules List ........................95 Figure 67: LED Scheduling Sample ..................... 96 Figure 68: Access Points ........................99 Figure 69: Choosing multiple devices ....................99 Figure 70: All-at-Once and Sequential Upgrade ................. 100 P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
-
Page 12: Document Purpose
DOCUMENT PURPOSE This document describes how to configure the GWN7610/GWN7600/GWN7600LR via Web GUI in standalone mode, with other GWN76XX Access Points as Master/Slave architecture and more. The intended audiences this document network administrators. Please visit to download the latest “GWN7610/GWN7600/GWN7600LR User http://www.grandstream.com/support... -
Page 13: Change Log
CHANGE LOG This section documents significant changes from previous versions of the GWN7610/GWN7600/GWN7600LR user manuals. Only major new features or major document updates are listed here. Minor updates for corrections or editing are not documented here. Firmware Version 1.0.8.18 Product Name: GWN7610 / GWN7600 / GWN7600LR ... -
Page 14: Firmware Version 1.0.6.41
Added support for Transfer AP and Transfer Network Group. [Transfer AP – Transfer Network Group] Firmware Version 1.0.6.41 Product Name: GWN7600 / GWN7600LR Added date time display on Overview Page. [Overview Page] Added new feature scheduling module. [SCHEDULE] ... -
Page 15: Firmware Version 1.0.4.22
Added support for Configurable Web UI access port [Web HTTP Access] Added support for E-mail notifications [Email/Notification] Firmware Version 1.0.4.12 Product Name: GWN7600 / GWN7600LR Added support for Timed Client Disconnect and Enhanced Client Blocking [CLIENTS CONFIGURATION] ... -
Page 16: Firmware Version 1.0.3.21
Firmware Version 1.0.3.21 Product Name: GWN7610 No major changes. Firmware Version 1.0.3.19 Product Name: GWN7610 / GWN7600 / GWN7600LR Added support for captive portal [CAPTIVE PORTAL] Added support for 802.11k/r/v [Enable Voice Enterprise] Added support for failover master [Failover Master] ... -
Page 17: Firmware Version 1.0.1.31
Added support for Password change on first boot. [Figure 17: Change Password on First Boot] Added Country code selection into setup wizard. Firmware Version 1.0.1.31 Product Name: GWN7600 / GWN7600LR This is the initial version. Firmware Version 1.0.1.27 Product Name: GWN7610 ... -
Page 18: Welcome
This wireless access point can be paired with any third party routers as well as Grandstream GWN series routers. With support for advanced QoS, low-latency real-time applications, 450+ concurrent client devices per AP and dual Gigabit network ports with PoE, the GWN7600/GWN7600LR is an ideal WiFi access point for medium wireless network deployments with medium-to-high user density. - Page 19 Note (VU#228519): “Out of the box” Grandstream Access Points are not affected by this issue. APs with old firmware are only affected after changing into client-bridge mode. Please refer to our white paper of “WPA Security Vulnerability” here. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
-
Page 20: Product Overview
802.11b:-92dBm@11Mbps; 802.11g:-76dBm@54Mbps; 802.11n 20MHz: -73dBm@MCS7; 802.11n 40MHz:-70dBm@MCS7 Receiver Sensitivity 802.11a:-94dBm@6Mbps; 801.11a:-77dBm@54Mbps; 802.11ac 20MHz: -69dBm@MCS8; 802.11ac HT40:-65dBm@MCS9; 802.11ac 80MHz: 1dBm@MCS9 * Receiver sensitivity varies by frequency band, channel width and MCS rate P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 21: Table 2: Gwn7600 Technical Specifications
Entire Package Dimension: 258 x 247 x 86mm; Entire Package Weight: 900g GWN7610 802.11ac Wireless AP, Mounting Kits, Quick Start Guide Package Content FCC, CE, RCM, IC Compliance Table 2: GWN7600 Technical Specifications Wi-Fi Standards IEEE 802.11 a/b/g/n/ac (Wave-2) 2x 2.4 GHz, gain 3 dBi, internal antenna Antennas 2x 5 GHz, gain 3 dBi, internal antenna IEEE 802.11ac: 6.5 Mbps to 877 Mbps... - Page 22 LEDs for device tracking and status indication Network Protocols IPv4, 802.1Q, 802.1p, 802.1x, 802.11e/WMM 802.11e/WMM, VLAN, TOS Network Embedded controller in GWN7600 allows it to auto-discover, auto-provision and Management manage up to 30 GWN76XX in a network DC Input: 24VDC/1A Power and Green Power over Ethernet (802.3af) compliant...
-
Page 23: Table 3: Gwn7600Lr Technical Specifications
Unit + Mounting Kits Dimension: 205.3 x 205.3 x 53.9mm; Unit + Mounting Kits Physical Weight : 610g Entire Package Dimension: 228.5*220*79mm; Entire Package Weight: 854g GWN7600 Wave-2 802.11ac Wireless AP, Mounting Kits, Quick Installation Guide Package Content FCC, CE, RCM, IC Compliance... - Page 24 Entire Package Weight: 1844g Enterprise 802.11ac Wave-2 Outdoor Long Range WiFi Access Point, Mounting Package Content Kits, Quick Installation Guide Waterproof Grade IP66-level weatherproof capability when installed vertically FCC, CE, RCM, IC Compliance P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
-
Page 25: Installation
INSTALLATION Before deploying and configuring the GWN7610/GWN7600/GWN7600LR, the device needs to be properly powered up and connected to the network. This section describes detailed information on installation, connection and warranty policy of the GWN7610/GWN7600/GWN7600LR. Equipment Packaging Table 4: GWN7610/GWN7600 Equipment Packaging... -
Page 26: Table 5: Gwn7600Lr Equipment Packaging
Assembled Screw Yes (4) Locknut Yes (4) Anchors + Screws Yes (4) Screw (PM8 x 115) Yes (4) Quick Installation Guide Yes (1) GPL License Yes (1) Figure 2: GWN7600LR Equipment Package P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 27: Gwn7610/Gwn7600/Gwn7600Lr Access Point Ports
GWN7610/GWN7600/GWN7600LR Access Point Ports Figure 3: GWN7610/GWN7600 & GWN7600LR Ports Table 6: GWN7610/GWN7600 Ports Description Port Description Power Power adapter connector (24V, 1A) NET/PoE Ethernet RJ45 port (10/100/1000Mbps) supporting PoE (802.3af). Ethernet RJ45 port (10/100/1000Mbps) to your router or another GWN76xx series USB 2.0 port (for future IOT &... -
Page 28: Power And Connect Gwn7610/Gwn7600/Gwn7600Lr Access Point
GWN7600LR). Step 3: For GWN7610/GWN7600 only, connect the 24V DC power adapter into the power jack on the back of the access point. Insert the main plug of the power adapter into a surge-protected power outlet. Otherwise, PoE can be used if the switchport does provide PoE power. -
Page 29: Warranty
Authorization) number before the product is returned. Grandstream reserves the right to remedy warranty policy without prior notification. Wall and Ceiling Mount Installation for GWN7610/GWN7600 GWN7610/GWN7600 can be mounted on the wall or ceiling, please refer to the following steps for the appropriate installation. Wall Mount... -
Page 30: Ceiling Mount
Figure 9: Ceiling Mount – Step 3 Step 5: Align the arrow on the GWN7600 AP with the arrow on the locking tab of the mounting bracket and ensure that your GWN is firmly seated on the mounting bracket and connect the network and power cables. -
Page 31: Mounting Instructions For Gwn7600Lr
5. Align the GWN7600LR with the Base Bracket and pull it down to the right position. 6. Install the 2x Assembled screws to fix GWN7600LR on the Mounting Bolt. Figure 12: GWN7600LR Vertical Mounting Figure 13: GWN7600LR Horizontal Mounting P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 32: Getting Started
GWN7610/GWN7600/GWN7600LR and use its Web GUI interface. LED Patterns The panel of the GWN7610/GWN7600/GWN7600LR has different LED patterns for different activities, to help users read the status of the GWN7610/GWN7600/GWN7600LR whether it’s powered up correctly, provisioned, in upgrading process and more, for more details please refer to the below table. -
Page 33: Discover The Gwn7610/Gwn7600/Gwn7600Lr
1. Locate the MAC address on the MAC tag of the unit, which is on the underside of the device, or on the package. 2. From a computer connected to same Network as the GWN7610/GWN7600/GWN7600LR, type in the following address using the GWN7610/GWN7600/GWN7600LR’s MAC address on your browser https://gwn_<mac>.local... -
Page 34: Method 2: Discover The Gwn7610/Gwn7600/Gwn7600Lr Using Gwn Discovery Tool
2. Open the GWNDiscoveryTool, click on Select to define the network interface, then click on Scan. 3. The tool will discover all GWN7610/GWN7600/GWN7600LR Access Points connected on the network showing their MAC, IP addresses and firmware version. 4. Click on Manage Device to be redirected directly to the GWN7610/GWN7600/GWN7600LR's configuration interface, or type in manually the displayed IP address on your browser. -
Page 35: Access Web Gui
Ensure the device is properly powered up. Open a Web browser on the computer and type in the URL using the MAC address as shown in [Discover the GWN7610/GWN7600/GWN7600LR] or the IP address using the following format: https://IP_Address Enter the administrator’s login and password to access the Web Configuration Menu. The default administrator's username and password are "admin"... -
Page 36: Web Gui Languages
Figure 17: Change Password on First Boot WEB GUI Languages Currently the GWN7610/GWN7600/GWN7600LR series web GUI supports English and Simplified Chinese. Users can select the displayed language at the upper right of the web GUI either before or after login. -
Page 37: Overview Page
Dashboard style for easy monitoring along with firmware version and date-time information at the top. Figure 20: GWN76xx Dashboard (GWN7600 as example) Users can quickly see the status of the GWN7610/GWN7600/GWN7600LR for different items, please refer to the following table: Table 9: Overview Shows the number of Access Point that are Discovered, Paired (Online) and Offline. -
Page 38: Save And Apply Changes
New Firmware Notification: Starting from firmware version 1.0.5.13/1.0.5.14, and once a different OFFICIAL firmware is released on Grandstream Networks website, the master AP will popup reminder notification to the administrator in order to upgrade the device. You can click on... -
Page 39: Gwn.cloud
GWN.CLOUD Starting from firmware 1.0.6.41/1.0.6.43, the GWN7610/GWN7600/GWN7600LR can be managed by your GWN.Cloud account, GWN.Cloud web interface now can be accessed at https://www.gwn.cloud. Please refer to for how to add your GWN AP to GWN.Cloud. GWN.Cloud User Guide Figure 22: GWN.Cloud Login Page... -
Page 40: Using Gwn76Xx As Standalone Access Point
USING GWN76XX AS STANDALONE ACCESS POINT The GWN7610/GWN7600/GWN7600LR can be used in Standalone mode, where it can act as Master Access Point Controller or in Slave mode and managed by another GWN76xx Master. This section will describe how to use and configure the GWN7610/GWN7600/GWN7600LR in standalone mode. -
Page 41: Using Gwn76Xx As Master Access Point Controller
Master GWN76XX and can only act as a Master Access point controller. Users will need to perform a factory reset to the GWN7610/GWN7600/GWN7600LR, or unpair it from the initial GWN76XX to make it open to Master Access Point mode again. -
Page 42: Login Page
GWN76XX accepts option 224 encapsulated in option 43, and the syntax is in TLV format. A simple example of DHCP 43 configuration would be: 224(Type)12(Length)10.157.0.234(Value) translated into Hex as e00c31302e3135372e302e323334 P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 43: Figure 26: Discover And Pair Gwn7610/Gwn7600/Gwn7600Lr
Network GWN7610/GWN7600/GWN7600LR follows the below steps: 1. Connect to the GWN7610/GWN7600/GWN7600LR Web GUI as Master and go to Access Points. Figure 26: Discover and Pair GWN7610/GWN7600/GWN7600LR 2. Click on to discover access points within GWN76xx Network, the following page will appear. -
Page 44: Table 10: Device Configuration
Uptime, and Users count via different Radio channels. Clients Shows the connected users to the GWN76xx access point. Device Name: Set GWN7610/GWN7600/GWN7600LR’s name to be shown next to MAC address. Fixed IP: Set a static IP for the GWN76xx, default is unchecked. - Page 45 -70dbm. Otherwise, power will not be adjusted. Coverage Hole Detection: CHD enables AP to decide whether to increase the AP power by the current SNR and SNR threshold of the connected clients. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
-
Page 46: Ap Location
Note If a GWN7610/GWN7600/GWN7600LR is not being discovered or the pair icon is grey color, make sure that it is not being paired with another GWN76XX Access Point acting as Master Controller, if yes users will need to unpair it first, or reset it to factory default settings in order to make it available for pairing by... -
Page 47: Failover Mode
During the failover mode users could access the web GUI of the failover slave using a special failover account with same admin password. Username = failover Password = admin password P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 48: Figure 30: Failover Mode Gui
When Failover Slave is switched to Master, you will use the Prior Master AP credentials: username: admin, and the admin password. Otherwise, when original master comes back online, then Failover Slave will become slave again to prior original Master. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 49: Client Bridge
Users must enable client bridge support option under SSID or SSID WiFi settings in order to have it fully functional. See [Client Bridge Support] P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 50: Ssid
SSID When using GWN7610/GWN7600/GWN7600LR as Master Access Point, users can create different SSIDs and assign GWN76xx Slave Access Points to them. Log in as Master to the GWN7610/GWN7600/GWN7600LR WebGUI and go to SSIDs. Figure 32: SSID GWN7610/GWN7600/GWN7600LR can support up to 16 SSIDs, click on to add a new SSID. -
Page 51: Table 11: Wi-Fi
WPA2: Using “PSK” or “802.1x” as WPA Key Mode, with “AES” or “AES/TKIP” Encryption Type. Recommended configuration for authentication. Open: No password is required. Users will be connected without authentication. Not recommended for security reasons. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... - Page 52 This field is available only when “WPA Key Mode” is set to “802.1x”. Enter the secret password for client authentication with RADIUS RADIUS Accounting Server accounting server. Secret This field is available only when “WPA Key Mode” is set to “802.1x”. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
- Page 53 WiFi. Three modes are available: Radio Mode: Wireless clients can access to the internet services, GWN7xxx router and the access points GWN7610/GWN7600 and GWN7600LR but they cannot communicate with each other. Client Isolation Internet Mode: Wireless clients will be allowed to access only the...
- Page 54 Default value is 1, meaning that AP will have DTIM broadcast every beacon. If set to 10, AP will have DTIM broadcast every 10 beacons. Valid range: 1 – 10. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
- Page 55 This option will enable GWN AP to answer the ARP requests from its LAN ARP Proxy for its connected WiFi clients. This is mainly to reduce the airtime consumed by ARP Packets P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
-
Page 56: Figure 34: Device Membership
Device Membership: Used to add or remove paired access points to the SSID. Figure 34: Device Membership Click on to add the GWN7610/GWN7600/GWN7600LR to the SSID or click on to remove it. P a g e GWN7610/GWN7600/GWN7600LR User Manual... -
Page 57: Clients Configuration
Below we discuss each section of this menu: Clients Users can access clients list connected to GWN7610/GWN7600/GWN7600LR from Web GUI Clients Clients to perform different actions to wireless clients. Figure 35: Clients ... -
Page 58: Clients Access
From this menu, users can manage in global way the blacklist of clients that will be blocked from accessing the WiFi network, click on to add or remove MAC addresses of client from global blacklist. Figure 37: Global Blacklist P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 59: Figure 38: Managing The Global Blacklist
Users can check « Enable Schedule » to assign a schedule for the list when it will take effect. Figure 40: Adding New Access List Once this is done, this access list can be used under SSID WiFi settings to filter clients either using whitelist or blacklist mode. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 60: Time Policy
Table 12: Time Policy Parameters Option Description Name Enter the name of the policy Enabled Check the box to enable the policy Limit Client Connection Time Sets amount of time a client may be connected. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 61: Banned Clients
Figure 42: Ban/Unban Client P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 62: Captive Portal
Captive Portal feature on GWN7610/GWN7600/GWN7600LR AP helps to define a Landing Page (Web page) that will be displayed on Wi-Fi clients’ browsers when attempting to access Internet. Once connected to a GWN7610/GWN7600/GWN7600LR AP, Wi-Fi clients will be forced to view and interact with that landing page before Internet access is granted. -
Page 63: Policy List
The policy configuration page allows adding multiple captive portal policies which will be applied to SSIDs and contains options for different authentication types a splash page that can be easily configured as shown on the next section. Administrator can use an internal or external splash page. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 64: Internal Splash Page
Table 13: Captive Portal – Policy List – Splash Page is “Internal” Field Description Name Enter the name of the Captive Portal policy Splash Page Select Splash Page type, Internal or External. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... - Page 65 Set the key for the portal, once clients want to connect to the WiFi, they should Facebook APP Key enter this key. Twitter Check this box to enable Twitter Authentication. Force to Follow If checked, users need to Follow owner before been authenticated. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
- Page 66 URL Address Page”. Once enabled, guest can authenticate once every day, and he cannot re- Enable Daily Limit authenticate after the first authentication expired. The authentication will reset every 0 o'clock. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
-
Page 67: External Splash Page
Configures the address for the RADIUS accounting server. Server Address RADIUS Accounting Configures RADIUS accounting server listening port (default is 1813). Server Port RADIUS Accounting Enter the secret password for client authentication with RADIUS accounting Server Secret server. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 68: Figure 47: Authentication Rules
SSH connections. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 69: Splash Page
Vouchers Voucher Feature Description Voucher feature will allow clients to have internet access for a limited duration using a code that is randomly generated from GWN controller. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 70: Voucher Configuration
The admin can verify the status of each vocoder on the list (In use, not used, expired …etc). Press to print the voucher, to delete it or to renew the voucher. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 71: Figure 49: Add Voucher Sample
Figure 49: Add Voucher Sample The below figure shows the status of the vouchers after GWN randomly generates the code for each one. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 72: Table 15: Voucher Parameters
Create Number One Time profile/settings (duration, bandwidth and number of users). Valid range: 1 – 1000. Specify how many users can use same voucher. Max Devices Valid range: 1 – 5. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 73: Using Voucher With Gwn Captive Portal
1. Go under “Captive Portal Captive portal” menu. 2. Press in order to add new captive portal policy. 3. Set the following parameters as shown on the screenshot for basic setup then save and apply. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 74: Figure 51: Captive Portal With Voucher Authentication
Figure 51: Captive Portal with Voucher authentication Then go under your SSID configuration page and enable the generated captive portal under WiFi settings tab. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 75: Mesh Network
AP in the “Online Wireless” state is the RE (Range Extender) with a wireless uplink to the CAP. The APs showing “Online” state are either a wired master or CAP. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 76: Figure 52: Access Points Status
Figure 52: Access Points Status For Global mesh network settings, navigate to the menu “System Settings Mesh” for setting up the following parameters described below: Figure 53: Mesh settings P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 77: Table 16: Mesh Configuration
1 and maximum value is 4. Table 16: Mesh configuration For more detailed information about GWN Mesh network feature, you may refer to the following technical document: Mesh Network Guide. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 78: Bandwidth Rules
BANDWIDTH RULES The bandwidth rule is a GWN7610/GWN7600/GWN7600LR feature that allows users to limit bandwidth utilization per SSID or client (MAC address or IP address). This option can be configured from the GWN7610/GWN7600/GWN7600LR WebGUI under “Bandwidth Rules”. Click to add a new rule, the following table provides an explanation about different options for bandwidth rules. -
Page 79: Figure 54: Mac Address Bandwidth Rule
The same settings for bandwidth management are available from the following menus: Per-Client Navigate on the web GUI under “ClientsEditBandwidth Rules” where you can set the Upstream and Downstream rate in Mbps. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 80: System Settings
SYSTEM SETTINGS Maintenance Users can access Maintenance page from GWN7610/GWN7600/GWN7600LR WebGUISystem Settings Maintenance. Basic Basic page allows Country and Time configuration. Table 18: Basic Field Description Enables Web HTTP Access. By default, it’s disabled. Web HTTP Access Web HTTPS Port Specifies HTTPS port. -
Page 81: Upgrade
Defines the day of the week to check the HTTP/TFTP server for firmware upgrade or configuration file changes. Day of Week This field is available when select “Check at Day of Week” in “Automatic Upgrade” P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 82: Access
Configure the password for user-level Web GUI access. This field is case New User Password sensitive with a maximum length of 32 characters. Confirm New User Enter the new User password again to confirm. Password P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 83: Syslog
Check to log DNS Queries. Logserver The logserver page allows the user to configure syslog server on GWN7610/GWN7600/GWN7600LR in order to save log messages on connected external USB drive. First connect a USB drive to the Access point, then configure the parameters and make sure to start the server in order to collect messages from devices sending syslog to GWN. -
Page 84: Debug
Press Clear button to remove logs. Debug GWN7610/GWN7600/GWN7600LR offers many features for managing and monitoring connected clients to SSIDs, as well as debugging and troubleshooting. Capture (GWN7610/GWN7600 Only) This section is used to generate packet trace captures from SSIDs interfaces which will help to sniff packets within the SSID for troubleshooting purpose or monitoring. -
Page 85: Table 23: Debug
Set a File size that the capture will not exceed. Rotate Count Set a value for rotating captures. Choose if you want to get all traffic or only outgoing or incoming to the chosen Direction interface. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 86: Figure 57: Capture Files
Click on next to a capture file to download it on a local folder. Click on to delete the corresponding capture file. Figure 57: Capture Files P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 87: Core Files
Ping and Traceroute are useful debugging tools to verify reachability with other clients across the network. The GWN7610/GWN7600/GWN7600LR offers both Ping and Traceroute tools for IPv4 and IPv6 protocols. To use these tools, go to GWN7610/GWN7600/GWN7600LR WebGUI System Settings Debug Ping/Traceroute. -
Page 88: Syslog
Figure 59: IP Traceroute Syslog The syslog Web page displays logs generated by the GWN7610/GWN7600/GWN7600LR for troubleshooting purpose as shown in figure below. Syslog messages are also displayed in real time under Web GUISystem SettingsDebugSyslog. Figure 60: Syslog P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 89: Email/Notification
Specifies sender’s password of the email account. Password Email Address Specifies the email address of the administer where to receive notifications. Skip Certificate Check this box to skip the certificate validation Validation P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 90: Table 25: Email Events
Specifies the Memory Usage Threshold (%). Must be integer between 1 and 100. Threshold (%) Configures whether to send notification if CPU usage is greater than the configured CPU Usage threshold. By default, it’s disabled. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 91: Dhcp Sever
DHCP Start Address Set the start address for DHCP DHCP End Address Set the end address for DHCP DHCP Lease Time Set the DHCP lease time for the clients (default 12h). P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 92: Static Dhcp
3. Enter the name of the device, along with its MAC address and IP address Figure 63: DHCP Binding 4. Press Save and Apply to submit the changes. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 93: Figure 64: Static Dhcp Devices List
Figure 64: Static DHCP Devices List P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 94: Schedule
4. Once the schedule periods are selected, click on Save to save the schedule. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 95: Figure 66: Schedules List
The list of created schedules will be displayed as shown on the figure below. With the possibility to edit or delete each schedule: Figure 66: Schedules List P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 96: Led Schedule
LED SCHEDULE GWN7610/GWN7600/GWN7600LR Access Points series support also the LED schedule feature. This feature is used to set the timing when the LEDs are ON and when they will go OFF at customer’s convenience. This can be useful for example when the LEDs become disturbing during some periods of the day, this way with the LED scheduler, you can set the timing so that the LEDs are off at night after specific hours and maintain the Wi-Fi service for other clients without shutting down the AP. -
Page 97: Upgrading And Provisioning
UPGRADING AND PROVISIONING Upgrading Firmware The GWN7610/GWN7600/GWN7600LR can be upgraded to a new firmware version remotely or locally. This section describes how to upgrade your GWN7610/GWN7600/GWN7600LR. Upgrading via Web GUI The GWN7610/GWN7600/GWN7600LR can be upgraded via TFTP/HTTP/HTTPS by configuring the URL/IP Address for the TFTP/HTTP/HTTPS server and selecting a download method. -
Page 98: Upgrading Slave Access Points
Upgrading Slave Access Points When GWN7610/GWN7600/GWN7600LR being paired slave using another GWN7610/GWN7600/GWN7600LR Access Point acting as Controller, users can upgrade their paired access points from the GWN7610/GWN7600/GWN7600LR Master Controller. P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18... -
Page 99: Sequential Upgrade
To upgrade a slave access point, log in to the GWN7610/GWN7600/GWN7600LR acting as Master Controller and go to Access Points. Figure 68: Access Points Make sure that firmware server path is set correctly under Maintenance, check the desired APs to upgrade, and click on to upgrade the selected paired access points. -
Page 100: Provisioning And Backup
Users can upload configuration file to the GWN7610/GWN7600/GWN7600LR under Web GUISystem SettingsMaintenanceUpgrade. Click on to browse for the configuration to upload. Please note that the GWN7610/GWN7600/GWN7600LR will reboot after the configuration file is restored successfully. P a g e GWN7610/GWN7600/GWN7600LR User Manual... -
Page 101: Configuration Server
Configuration Server Users can download and provision the GWN7610/GWN7600/GWN7600LR by putting the config file on a TFTP/HTTP or HTTPS server and set Config Server to the TFTP/HTTP or HTTPS server used in order for the GWN7610/GWN7600/GWN7600LR to be provisioned with that config server file. -
Page 102: Experiencing The Gwn76Xx Wireless Access Points
Thank you again for purchasing Grandstream GWN7610/GWN7600/GWN7600LR Wireless Access Point, it will be sure to bring convenience and color to both your business and personal life P a g e GWN7610/GWN7600/GWN7600LR User Manual Version 1.0.8.18...
