Grandstream GWN series routers. With support for advanced QoS, low-latency real-time applications, 450+ concurrent client devices per AP and dual Gigabit network ports with PoE, the GWN7600 is an ideal WiFi access point for medium wireless network deployments with medium-to-high user density.
Page 2
3 tri-color LEDs for device tracking and status indication LEDs IPv4, 802.1Q, 802.1p, 802.1x, 802.11e/WMM Network Protocols 802.11e/WMM, VLAN, TOS Embedded controller in GWN7600 allows it to auto-discover, auto-provision and manage up to 30 Network Management GWN7600s in a network DC Input: 24VDC/1A Power and Green Energy Eiciency Power over Ethernet (802.3af) compliant...
This allows each access point to manage a network of up to 30 GWN7600 series APs independently without needing separate controller hardware/software and with- out a single point-of-failure.
HARDWARE INSTALLATION GWN7600 can be mounted on the wall or ceiling, Please refer to the following steps for the appropriate installation. Wall Mount 1. Position the mounting bracket at the desired location on the wall with the arrow pointing 2. Use a pencil to mark the four mounting holes (screw holes DIA 5.5mm, reticle hole DIA 25mm).
Page 5
(screw holes DIA 5.5mm, reticle hole DIA 25mm). 5. Align the arrow on the GWN7600 with the arrow on the locking tab of the mounting bracket and ensure that your GWN7600 is frmly seated on the mounting bracket.
Page 6
Network Port 5. Align the arrow on the GWN7600 with the arrow on the locking tab of the mounting bracket and ensure that your GWN is irmly seated on the mounting bracket and connect bracket and ensure that your GWN7600 is irmly seated on the mounting bracket and connect the network and power cables.
GWN7600’s MAC address on your browser https://gwn_<mac>.local - If the GWN7600 is already paired, make sure to unpair it irst, or do a factory reset. Example: if a GWN7600 has the MAC address 00:0B:82:8B:4E:28, this unit can be ac- - For more information, please download the GWN7600 User Manual from: cessed by typing https://gwn_000b828b4e28.local on the browser.
Page 8
FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
