6 Technical parameters

7 LED signalling of digital inputs

LEDs (Figure 1, no. 5) for digital inputs inform about activation of connected
LED for input:
COM1
– ▲ lights at short-circuit of the contact responsible for sending command open
– ▼ lights at short-circuit of the contact responsible for sending command close
– ▼▲ light at short-circuits of the contacts responsible for sending command stop
COM 2, COM 3 and COM 4 analogously
13.11.21 NC825-GB
Power
Working temperature
Working range
Working frequency
Maximum cable length of the device plugged into
digital or analogue input
Technical parameters
13/16
230VAC
(+5 O C) to (40 O C)
To 40 [m]
868,42 MHz
5 rm
controllers..
