INSTALLATION
6. Connect the coiled tubes to the inlet and outlet of the MDM300. Ensure
that the 1/8" Swagelok
7. Secure the instrument to the mounting posts using the supplied 2.5mm
hex bolts and allen key.
8. Use a wrench/spanner to fi nish tightening the 1/8" Swagelok
inlet/outlet to ensure there are no leaks. The body of the 1/8" NPT to 1/8"
Swagelok
while the nuts are tightened to prevent any movement.
4
MDM300 Sampling System User's Manual
nuts are fi nger tight.
®
Figure 4 MDM300 Inlet and Outlet Port Connection
Figure 5
adaptor should be held securely with another wrench/spanner
®
Figure 6
I S
- I.S.
Mounting Posts
- I.S.
Port Connection Tightening
97232 Issue 1.4, October 2016
nuts on the
®
