Raritan Dominion KX IV-101 Package Contents

Dominion KX IV–101
(DKX4-101)
Thank you for purchasing the Dominion KX
IV–101, part number DKX4-101.
Package Contents
• 1 Dominion KX IV–101
• 1 locking power cord
• 1 HDMI cable
• 1 USB-B to USB-A cable
• 1 mounting bracket kit
QS Rule
Front View
Local Port HDMI Out to local port monitor
Local Port USB K/M
Input/Output
Reset
Power Status LED:
• Green ON: Power on
• Green BLINKING: Remote target connection
QS Rule
KX4-101 QSG
QSG-KX4101-1A-v4.0.0-E  255-62-0022-00-RoHS

QUICK SETUP GUIDE

Rear View
Power 5V/4A from power adapter
RJ-45 LAN Network Port with 2 LEDs for network
speed and activity:
• Amber OFF/Green OFF: Link Inactive
• Amber ON/Green OFF: 1000 MBps Link/No
Activity
• Amber BLINKING/Green OFF: 1000 MBps
Link/Activity(RX, TX)
• Amber OFF/Green ON: 100 MBps Link/No Activity
• Amber OFF/Green BLINKING: 100 MBps
Link/Activity(RX, TX)
Amber ON/Green ON: 10 MBps Link/No Activity
•
Amber BLINKING/Green BLINKING: 10 MBps
•
Link/Activity(RX, TX)
Serial Admin Port
USB In from target server
HDMI In from target server
