Raritan DOMINION KX 101 Brochure

Switchless, scalable, single-target kvm control via web browser

Advertisement

Quick Links

Specifications
Dominion KX 101
Dominion KX Model
KX101
Form Factor
Zero U form factor; rack mountable vertically or
horizontally (bracket kit included)
Dimensions (DxWxH)
103 x 74 x 27mm
Weight
0,286kg
Power
AC/DC (100-240V~/ 6VDC) power adapter
or
Power over Ethernet (PoE)
– Mid-Span Power Insertion
– Signal-Pair Power Insertion
Operating temperature 0° - 40°C
Humidity
20% – 85% RH
Indicators:
Blue RARITAN back-lit logo
Boot-up and power-level indicator
Green LED
Network activity
Local connection
Serial Admin Console Port 1 – RJ11 port for RS232 serial communication connection
Remote Connection:
Network
One 10/100 Ethernet (RJ45) port
Protocols
TCP/IP, HTTP, HTTPS, UDP, RADIUS, LDAP, SNTP, DHCP
Screen Resolutions:
Up to 1600 X 1200 @ 60Hz
PC graphic mode
640 X 480 @ 60/72/75/85Hz,
SUN® video mode
800 X 600 @ 56/60/72/75/85Hz,
1024 X 768 @ 60/70/75/85Hz,
1152 X 864 @ 60/75Hz,
1280 X 1024 @ 60Hz,
1600 X 1200 @ 60Hz
Warranty
Two years.
In addition, Raritan offers two years extended warranty.
When you're ready to take control,
do it with Dominion KX.
Call +31-10-2844040 or visit
Raritan.info
©2005 Raritan Computer, Inc. Raritan, CommandCenter and Dominion are registered trademarks of Raritan Computer, Inc.; Sun is a registered trademark of Sun
Microsystems, Inc.; Active Directory and Windows are registered trademarks of Microsoft Corp.; Novell is a registered trademark of Novell, Inc.; UNIX is a registered trademark
of UNIX System Laboratories, Inc.; PS/2 is a registered trademark of IBM Corporation; Linux is a registered trademark of Linus Torvalds; Mozilla is
a trademark of The Mozilla Organization; Mac is a registered trademark of Apple Computer, Inc.
Raritan is a leading supplier of solutions for managing IT infrastructure equipment, such as servers and networking hardware and the mission-critical applications and services that
run on it. Raritan was founded in 1985, and since then has been making products that are used to control millions of servers at more than 50.000 network data centers, computer
test labs and multi-workstation environments around the world. From the small business to the enterprise, Raritan's complete line of compatible and scalable KVM and remote
connectivity products offers IT professionals the most reliable, flexible and secure in-band and out-of-band solutions to manage data center equipment, applications and services,
while improving operational productivity. More information on the company is available at Raritan.info.
Raritan Europe., Eglantierbaan 16, 2908 LV Capelle aan den IJssel, The Netherlands
RJ45 (PoE Capable)
RJ11 Serial Port
DC Power Connection
KVM Cable (RGB, Mini Din 8)
KVM Interface Cable Adapter
PS2 Adapter
USB Adapter
Interface type
Length
Description
Video
38 cm
Integrated Cable
USB
60 cm
Attachment to integrated cable
PS2k
60 cm
Attachment to integrated cable
Sun
®
Requires APSUSB CIM
(not included in KX101 kit)
Raritan.info
KX101-Eur-Sep05
Dominion
KX
®
Switchless, Scalable,
Single-Target KVM Control
Via Web Browser
Enterprise-class KVM-over-IP in a palm-sized form factor
Dominion KX101 is a next-generation, enterprise-class KVM-over-IP device that
eliminates the blocking factor inherent in switched KVM architectures. It provides
anytime, anywhere access and BIOS-level control of a single server, via a dedicated
IP address. The Dominion KX101 shrinks all the performance and security features
of Raritan's industry-leading remote KVM access and control technology into a
Dominion KX 101
"zero-U," single-port density form factor.
1-Remote user, 1-Port
Multiple KX101s can be installed in a data center to provide fully non-blocked,
KVM over-IP
switchless access by any user to any server. Multiple KX101s also can be deployed
at multiple remote locations to provide anytime, anywhere, non-blocked access to
any device in a company's distributed infrastructure. All of the KX101s and many
other devices, including Raritan's Dominion KX, Dominion SX, Paragon II and
HP iLO/RILOE, can be centrally managed through a single IP address, with
Raritan's CommandCenter
Palm-sized and highly portable, the Dominion KX101 can be mounted vertically or
horizontally on the side of a rack, affixed to any convenient surface with Velcro
simply hung from the back of the target device by its cable. In addition, its Power-
over-Ethernet (PoE) capability can eliminate the need for a separate power supply
and cabling.
The Dominion KX101 is a fully featured member of Raritan's Dominion Series, so
it is engineered to:
Provide bulletproof security, feature-rich management functionality and the
highest quality video available, all over an IP network.
Integrate with all Raritan's other building blocks, to make it easy to build
exactly the solution you need
Work stand-alone or under the control of Raritan's CommandCenter Secure
Gateway centralized management appliance
Full Dominion Series feature set and innovative GUI
The Dominion KX101 is a small but complete package of next generation
KVM-over-IP innovations. It works with the industry's widest range of browsers
and operating systems, so you can use almost any combination of OS and browser.
It also incorporates Raritan's Virtual KVM Desktop™ features to provide a user
experience that is indistinguishable from an "at the rack" connection.
In addition, the Dominion KX101 is incredibly scalable.
Because it's CommandCenter-Ready™, literally thousands of Dominion KX101 units
can be integrated through Raritan's CommandCenter Secure Gateway into a single
logical network, with a single sign-on to a single IP address.
®
Secure Gateway.
®
Raritan.info
