Grecom PSR-800 Owner's Manual page 81

Slow Flash - Single Color
Flash Pattern
On Time
Off Time
LED Enable
LED Flash
Color Count
Color 1
Color 2
Color 3
Color 4
These settings will illuminate the LED with a single color, flashing on and off at
the rate of one cycle per second.
Slow Flash - Two Color
Flash Pattern
On Time
Off Time
LED Enable
LED Flash
Color Count
Color 1
Color 2
Color 3
Color 4
The settings shown above will illuminate the LED with a two colors, flashing on
and off at the rate of one cycle per second. The LED will be illuminated for 1/2
second and off for 1/2 second each period and will alternate colors each flash.
PSR-800 User Manual!
55555555
50
50
Checked
Checked
1
FF0000 (red)
n/a
n/a
n/a
55555555
50
50
Checked
Checked
2
FF0000 (red)
0000FF (blue)
n/a
n/a
Page 80
