SPECIFICATIONS

Engine
Type Honda 2:1
Horsepower 6.5hp (4.85 kw)
Lighting Coil Built into engine
Engine Cover Fully enclosed
Transmission
Manufacturer Eaton
Model Hydrostatic Series, 11
Oil Capacity
Engine 1.05qts (1L) + Filter
Transmission 6qts (6.84L) + Filter
Cooling
Engine Air cooled
Transmission 8 blade cooling fan
Drive Train 1/2" duplex chain,
self-adjusting
Drive Roller
Rubber coated, non-stick.
Flexible, contour following
Direction Control Ergonomically positioned foot pedals
Speed Control
Progressive foot pedal movement, down/
up Dampeners for smooth stopping
Operating Speed 0-9 mph (0-15kph)
Steering Joystick - Light load, directly connected to
smoothing head
R50-11 Owners Manual
Engine Vibration Isolated through rubber mounts
Seat Premium UV protected, with adjustable
armrests
Trailer
Integrated, extra heavy duty, folds from
rolling position to transport position
Ground Pressure
3.8 psi (26 kPa)
(Footprint)
Smoothing Heads 2 overlapping, fitted with tri-rollers in
each head, no gap between heads
Rolling Width 50" (1270mm)
(Swath)
Weight
726lb (330kg)
Drawbar
Lifting weight when 25lb (11kg)
connecting Quick release, pin built in
Pin style, standard
Tires
18 x 6.50 x 8. 4 ply
Engine Start/Stop
Recoil & Switch
Brake
Roller Hydrostatic
Park Handbrake, Drum style
OPS Seat Safety Operated through operator seat presence
Switch
or absence
Optional
Equipment ac/dc LED
Lights 15 blades, self-rotating on shaft & bearings
Slicer - Quick release Slice depth up to 30mm, (1 1/4")
Spiker - Quick release 30 wheels, self-rotating on SS shaft &
bearings. Spike depth 25mm, (1")
Brush - Quick release Stiff or Medium strength bristles available
Drawbar coupling 2" Ball style
(50mm) Suits Ball style drawbar only
Drop down leg
Warranty
2 years - Limited manufacturer's
warranty.
