Vetronix MTS 3100 Mastertech Operator's Manual page 32

Activating the Battery Backed Memory
Press Tab Down
3. See Figure 4-3 to remove the plastic strip covering the Lithium battery on the back of the tester.
Remove
Plastic
Strip
4. When the plastic strip is removed, slide the battery pack onto the tester with the tab at the top in the slot
on the tester. The battery pack should lock into place. For further information, see
5. See Chapter 5 to install a program card in the Mastertech.
6. Press the o key to turn the tester on. If the tester displays "ATTENTION! TESTER BATTERY
VOLTAGE IS LOW," see
7. The program card operator's manual explains how to setup the tester's internal functions. Some of the
internal functions are listed below.
• CLOCK/CALENDAR
• SELECT BAUD RATE
• SELECT PRINTER
• UNIT CONVERSION
Page 4-2
FIGURE 4-2. Activating Lithium Battery
FIGURE 4-3. Removing Strip on Lithium Battery
Chapter 8 to charge the batteries.
Slide Battery Pack
Toward Bottom of
Tester
NiCad Battery Pack
Lithium
Battery
Mastertech 3100 Operator's Manual
Chapter 8.
