Mastertech Kit Components
MASTERTECH FEATURES
The Mastertech Multi-Function Tester can be hand-held or placed on a flat surface. An adjustable hand strap
on the back provides added security while holding the tester.
A built-in support stand allows the tester to be tilted to the most convenient viewing angle when it is not
handheld.
LEDs
KEYBOARD
RS232 PORT
DLC
Page 3-2
DISPLAY
INSTRUMENTATION PORT
FIGURE 3-1. Tester Features
PROGRAM CARD
SCREEN CONTRAST
CONTROL
POWER CONNECTOR
NiCAD BATTERY PACK
Mastertech 3100 Operator's Manual
CARTRIDGE
SLOT
