Summary of Contents for YOKOGAWA SMARTDAC+ GM
- Page 1 Technical SMARTDAC+ GM and UPM100 Power Monitoring Package Information Wiring and Setup Guide TI 77C01H01-01EN Yokogawa Electric Corporation TI 77C01H01-01EN 2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan ©Copyright Oct. 2018 1st Edition Oct. 2018...
-
Page 2: How To Use This Manual
• Every effort has been made to ensure accuracy in the preparation of this manual. Should any errors or omissions come to your attention, however, please inform Yokogawa Electric’s sales office or sales representative. • Under no circumstances may the contents of this manual, in part or in whole, be transcribed or copied without our permission. - Page 3 Blank Page...
-
Page 4: Table Of Contents
Toc-1 SMARTDAC+ GM and UPM100 Power Monitoring Package Wiring and Setup Guide TI 77C01H01-01EN CONTENTS TOFC How to use this manual ...................i Overview ....................1-1 Device configuration and related documents ........1-2 Package specifications ................1-3 UPM connection settings ................ 1-4 Universal Viewer ..................1-7 Power monitor wiring precautions ............ - Page 5 Blank Page...
-
Page 6: Overview
Overview The Power Monitoring Package is a power monitoring system designed for smallscale applications. It consists of the SMARTDAC+ GM, the UPM100 Power Monitor, and a CTW fixed wire type current transformer. You can also select instruments and communication functions to meet your needs including RS-485 or Ethernet (with a VJET RS-485 to Ethernet converter). -
Page 7: Device Configuration And Related Documents
IM 77C01H01-10EN Manual Models CTW15 and CTW35 Clamp-on Current Transformers IM 77C01W03-01E Models CTW10, CTW20, CTW100, and CTW130 Clamp-on Current Transformers IM 77C01W02-01E You can download new versions of electronic documents from the following website. http://www.yokogawa.com/ns/powercert/im/ TI 77C01H01-01EN Oct. 17, 2018-00... -
Page 8: Package Specifications
Package specifications System architecture example Hardware Configurator Monitor on a tablet (UPM connection settings) Wi-Fi router Ethernet Web Application (Data display/UPM connection settings) Report file Universal Viewer (Data display) RS-485 Max. connected power monitors (UPM100) GM10-1: 20 GM10-2: 30 Communication specifications Select from the following: RS-485 or Ethernet (RS-485/Ethernet converter;... -
Page 9: Upm Connection Settings
UPM connection settings UPM Connection Settings is a settings wizard that implements all of the GM settings needed to connect the GM and UPM and display integration bar graphs. By using UPM Connection Settings, you can easily enter all of the settings needed for communication and display of integral graphs. You can use it with the hardware configurator (version 4.05.01 or later) and the web application (version 4.05.01 or later). Hardware Configurator/Web Application UPM connection settings Integral power calculation... - Page 10 UPM Connection Settings workflow Start UPM Connection Settings Start UPM Connection Settings. Precautions are displayed before UPM Connection Settings starts. Welcome screen From this screen you can load UPM connection settings files.* Select a communication mode for connecting the GM and UPM. [How to connect the GM10 For Ethernet, select a gateway device.
- Page 11 Examples of connections for communication RS-485 connection IP: 192.168.1.99 Master Ethernet (Address: 1) RS-485 IP: 192.168.1.1 UPM 1 UPM 2 UPM 3 Slave Slave Slave (Address: 2) (Address: 3) (Address: 4) Ethernet connection Client IP: 192.168.1.99 Ethernet IP: 192.168.1.1 Server (gateway) IP: 192.168.1.100 RS-485 VJET Unit: 1 (Address: 1)
-
Page 12: Universal Viewer
Universal Viewer Screens Integral graph display Legend, cursor value Toolbar Date picker display pane (fixed) Item Description Date setting Specify the date of the integral graph to display. Legend and cursor value The legend and cursor value are docked on the right edge of display area the screen Two graph comparison... -
Page 13: Power Monitor Wiring Precautions
Power monitor wiring precautions UPM100 Power Monitor wiring example Wiring without a VT (3 phase 3 wire example) With a VT Without a VT Note: If not using a VT, do not ground P2. This is an example with the UPM100, but the voltage input wiring is also the same on the PR300 and UPM101. - Page 14 Settings: VT ratio 60, CT ratio 100 110VAC 6600VAC 6600 500AAC 5AAC Power monitor CT load rating and wiring length ● CT load rating For the rated load, use a value within the sum of the wiring loss between the CT and the device connected to the secondary side, and the input loss to the device connected to the secondary side.
- Page 15 1-10 • When using wiring material of nominal cross section 2.00 mm Wiring resistance R =10 Ω/km × 0.015 km × 2 = 0.3 Ω Wiring loss ≈ I R = (secondary rated current) × wiring resistance = 1 × 1 × 0.3 = 0.3 VA Condition: CT rated load ≥ wiring loss + input loss of device cnctd. to secondary side 0.5 ≥ 0.3 + 0.2 = 0.5 VA This does meet the condition. CT handling precautions ● CT inspection and maintenance precautions Do not perform work while measuring lines are live. If the secondary side is open while CT current is flowing, high voltage occurs on the secondary side. This can cause insulation to degrade, and if left as-is, can cause burning and accidents and is extremely dangerous.
- Page 16 Wiring for communication between the Data Acquisition System GM and the UPM100 Power Monitor (RS-485 4 wire <=> 2 wire) Ethernet Approximately 1.2 km maximum length (up to 31 units) SMARTDAC+ GM UPM100 UPM100 UPM100 GM10 (RDA-) (RDB+) (SDA-) (SDB+) (SG)
-
Page 17: Power Package Application
1-12 Power package application Example of simultaneous measurement of quantities of vapor, gas, and other substances You can add a pulse module (for acquiring flow meter pulses) and measure flow quantities of power, vapor, and gas. ● System architecture SMARTDAC + GM RS-485 Flow meter UPM100 Flow meter For the pulse input module, use the GX90XP from the SMARTDAC+ SMARTDAC+ series. TI 77C01H01-01EN Oct. -
Page 18: Revision Information
Revision Information Title : SMARTDAC+ GM and UPM100 Power Monitoring Package Wiring and Setup Guide Manual number : TI 77C01H01-01EN Oct. 2018/1st Edition Newly published Written by Yokogawa Electric Corporation Published by Yokogawa Electric Corporation 2-9-32 Nakacho, Musashino-shi, Tokyo 180-8750, JAPAN TI 77C01H01-01EN Oct. - Page 19 Blank Page...
