Model VCRH24

SPECIFICATIONS

Low profile gas hotplate, Vulcan model No.____________.
Stainless steel front, sides and front top ledge. 13" cooking
height on 4" legs. 25,000 BTU/hr. open burners with lift-off
heads. Cast iron top grates. Full width front crumb trays. One
infinite heat control valve for each burner. Standing pilot ignition
system.
" rear gas connection and convertible gas pressure
3
4
regulator for LP service.
Exterior Dimensions:
_____"w x 29.3" d x 13.3" h on 4" legs.
CSA design certified. NSF listed.
P.O. Box 696
Louisville, KY 40201
F-38311 (04/10)
G R I D D L E S
&
RESTAURANT SERIES GAS HOTPLATE

STANDARD FEATURES

a division of ITW Food Equipment Group LLC
Toll-free: 1-800-814-2028
Chef's Corner
Item #
B R O I L E R S
VCRH SERIES
VCRH12
12" wide
VCRH24
24" wide
VCRH36
36" wide
Stainless steel front, sides and front top ledge.
Full width front crumb trays.
13" cooking height on 4" adjustable legs.
25,000 BTU/hr. open burners with lift-off heads.
Cast iron top grates.
One infinite heat control valve for each burner.
Standing pilot ignition system.
¾" rear gas connection and convertible gas pressure
regulator for LP service.
Constructed standard for natural gas service. LP
conversion kit supplied with unit.
One year limited parts and labor warranty.
Local: 502-778-2791
Quote & Order Fax: 1-800-444-0602
C.S.I. Section 11420
