Figure 1
SYSTEM COMPONENT LAYOUT
Figure 6 is the layouts that will help you find the parts and components in your Emergency Lighting
Inverter. Maintenance should only be performed by factory-trained or qualified personnel. Do
not attempt to service. If you need technical assistance, please contact DSPM.
In most units, this switch is located on the inside of the left door of the system (see Figure 6—System
Component Layout for exact location). The bypass switch is used in case of a failure of the lighting in-
verter. If the lighting inverter fails, place the bypass switch in the "MAN" position. In this position the in-
verter section is bypassed allowing the load to be powered by the utility until the inverter can be repaired.
In case of system failure, contact factory for service.
Title: Micro
Doc No.: 018-1000-02
Description: Emergency Lighting Inverter User's Manual
Rev: NR Page#: - 17 -
Date: 07/26/2016
