Rotation Properties

Tool Path Properties

Selected object's line thickness
Selected object's line shape
Selected object's line color
Fill color inside
Fill shape inside
Rotate selected object by one degree. When
inputting
pressing button, object is rotated as much as
input angle
Rotate selected object as much as input angle.
Rotate and add new object as much as input
angle
It shows "pulled pressure" instead of real engraved
Depth depth, in which dept is deeper, pressing pressure is
larger
XY-axis
Indicate speed of XY-axis movement
speed
Z-axis speed Indicate speed that Z-axis is moved down to object
Z direction In moving to other engraving position, first, lift Z-axis
movement in order that tool is not contacted with material
height surface and then, appoint height.
Two times
Engrave designed content two times.
engraving
your wanted rotation
Selected tool path position
Selected tool path's total size
angle and
