Red Technology MAGIC-2 Instruction Manual page 17

Vise Center Calibration:
1. Prepare a rectangular or circular material and mark a dot on the center of the material with
marker pen.
2. Turn power ON pressing
3. Tool will move to the center of vise, then red laser pointer will be lit.
Button Use:
Short each button press moves the pointer to the left/bottom or right/top depending on its mode.
Long press of
Long press of
Short Press
Right
Move
Left
Move
16
●
, then release the button as soon as machine beeps.
●
button will change mode to left/right movement or top/bottom movement.
button saves pointer calibration and return home.
Long Press
Mode
Change
Left/Right
Top/Bottom
●
Short Press
Up
Move
Down
Move
Long Press
Save Calibration
and return home.
