Snapper SS5200E Parts Manual page 7

Frame, Handle, & Engine Group
Item Part No Qty
37 1723104 1
38 1716681 1
38 7076272 1
39 1960112 3
40 173206 1
41 1716676 1
42 1720640 1
43 7041954 1
44 7075342 1
45 7071895 1
46 7091757 1
47 7090011 2
48 7091267 1
49A 7075909 1
49B 1733209 1
Footnotes:
NOTE: * See your local Tecumseh distributor for service parts.
520 Single Stage Snow Thrower
Series 0 & 1
Description
HOSE CLAMP (worm type)
HOSE, Fuel, 5-1/2" long
HOSE, Fuel, 8-1/2" long
HOSE CLAMP, Wire Form
FILTER, Fuel
SNAP BUSHING, 1/4"
BRACKET, Starter Handle
HANDLE, Start (Mitten)
HOLDER, Snostik- Lower (5/16-18 thread)
HOLDER, Snostik- Upper
SCREW, #10-24 x 1-1/4" Hex Head Cap
WASHER, #10 Internal Tooth Lock
NUT, #10-24 Hex Center Lock
SNOW STICK
SNOW STICK w/Brush
7
Note
or 1679061 (Hose Clamp, Wire)
replaces 7075909
Manual No. 7006178
TP 400-5006-3-LE-N
