Snapper SX5200R, SX5200E Safety Instructions & Operator's Manual

Snapper SX5200R, SX5200E Safety Instructions & Operator's Manual

Single stage extended frame snow thrower series 0
Hide thumbs
Table of Contents

Advertisement

Quick Links

MODEL DESIGNATION
ENGINE HP
S – Single Stage Operation Model
X – Extended Frame Model
5 – 5.0 Engine HP (Engine Horse Power)
Thank you for buying a SNAPPER Product! Before operating your Snow Thrower, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance
with the operating instructions and common sense.
COPYRIGHT © 2000
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
S
X
SINGLE STAGE
EXTENDED FRAME
SNOW THROWER
5
20
0
20 – 20" Auger Width
0 – Series Designation
E – 110 Volt Electric Start
R – Recoil Start
INSTRUCTION No. 4-1997 (REV. 2, 3/30/00)
SERIES 0
MODELS
SX5200R
SX5200E
E
ENGINE OPTIONS
SERIES DESIGNATION
AUGER WIDTH
