Operator's Manual
Briggs & Startton Yard Power Products Group
Copyright ©
2006
Briggs & Startton Corporation
Milwaukee, WI USA. All Rights Reserved
520 Single Stage Snow Thrower
Revision 3,
Parts Manual for
McDonough, GA, 30253 U.S.A.
11/20/2006
Series 0 & 1
MODEL
SS5200E
SS5200R
SS5201E
SS5201R
Manual No.
TP 400-5006-3-LE-N
7006178
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Snapper SS5200E
Summary of Contents for Snapper SS5200E
-
Page 1: Single Stage Snow Thrower
Briggs & Startton Yard Power Products Group Copyright © 2006 Briggs & Startton Corporation Milwaukee, WI USA. All Rights Reserved Parts Manual for McDonough, GA, 30253 U.S.A. Revision 3, 11/20/2006 Series 0 & 1 MODEL SS5200E SS5200R SS5201E SS5201R Manual No. 7006178 TP 400-5006-3-LE-N... - Page 3 PAGE GROUP Frame, Handle, & Engine Group Auger Housing and Chute Group Auger and Drive Group Decal Group 520 Single Stage Snow Thrower Series 0 & 1 Table Of Contents Manual No. 7006178 TP 400-5006-3-LE-N...
-
Page 4: Frame, Handle, & Engine Group
Frame, Handle, & Engine Group Manual No. 7006178 520 Single Stage Snow Thrower TP 400-5006-3-LE-N Series 0 & 1... - Page 5 WASHER, .27 I.D. x .62 O.D. Footnotes: NOTE: * See your local Tecumseh distributor for service parts. 520 Single Stage Snow Thrower Series 0 & 1 Note was 1716632 ref. Snapper part no. 7027168 replaces 1716607 replaces 1716664 Manual No. 7006178 TP 400-5006-3-LE-N...
- Page 6 Frame, Handle, & Engine Group Manual No. 7006178 520 Single Stage Snow Thrower TP 400-5006-3-LE-N Series 0 & 1...
- Page 7 Frame, Handle, & Engine Group Item Part No Description 1723104 HOSE CLAMP (worm type) 1716681 HOSE, Fuel, 5-1/2” long 7076272 HOSE, Fuel, 8-1/2” long 1960112 HOSE CLAMP, Wire Form 173206 FILTER, Fuel 1716676 SNAP BUSHING, 1/4” 1720640 BRACKET, Starter Handle 7041954 HANDLE, Start (Mitten) 7075342...
-
Page 8: Auger Housing And Chute Group
Auger Housing and Chute Group Manual No. 7006178 520 Single Stage Snow Thrower TP 400-5006-3-LE-N Series 0 & 1... - Page 9 SCREW, Hex Washer Slotted Head Plastite #10-14 x 5/8” 1960282 CARRIAGE BOLT, 5/16-18 x 3/4” 1919326 WASHER, 5/16 1919438 NUT, Hex Lock ESNA Light 5/16-18 Footnotes: 520 Single Stage Snow Thrower Series 0 & 1 Note Snapper Red Part for .156 dia. Stud Manual No. 7006178 TP 400-5006-3-LE-N...
- Page 10 Auger Housing and Chute Group Manual No. 7006178 520 Single Stage Snow Thrower TP 400-5006-3-LE-N Series 0 & 1...
- Page 11 Auger Housing and Chute Group Item Part No Description 1716612 CHUTE 1931335 CARRIAGE BOLT, 5/16-18 x 1”, GR 5 1716642 WASHER, Octagon 1716624 WASHER, Rubber 7035744 KNOB, Wing (5/16-18 Black) 1920283 WASHER, 1-1/2 O.D. 1716631 DEFLECTOR, Chute 1720576 HANDLE, Chute Rotator Lower, E-Coat 1720577 TUBE, Chute Handles 1/2 OD 7.00 Long E-Coat 1926228...
-
Page 12: Auger And Drive Group
Auger and Drive Group Manual No. 7006178 520 Single Stage Snow Thrower TP 400-5006-3-LE-N Series 0 & 1... -
Page 13: Air Deflector
1716589 BELT GUARD Footnotes: 520 Single Stage Snow Thrower Series 0 & 1 Note (includes Ref. Nos. 10 & 11, plus fasteners and instructions) ref. Snapper part no. 7010948 Poly Rib J; 37.525” effective length Manual No. 7006178 TP 400-5006-3-LE-N... - Page 14 Auger and Drive Group Manual No. 7006178 520 Single Stage Snow Thrower TP 400-5006-3-LE-N Series 0 & 1...
-
Page 15: Control Panel
Auger and Drive Group Item Part No Description 1716654 IDLER PIVOT BOLT 1714055 FLANGE NUT, Ignition Switch, 5/8-32 1716637 CONTROL PANEL 1716627 HOUSING, Lower 1921319 WASHER, 1/4 1960568 SCREW, Hex Head, Taptite, 1/4-20 x 7/8” 1718337 SWITCH, Ignition 1716676 SNAP BUSHING, 1/4” 1714054 KEY, Ignition 1960595... -
Page 16: Decal Group
Decal Group Manual No. 7006178 520 Single Stage Snow Thrower TP 400-5006-3-LE-N Series 0 & 1... - Page 17 Decal Group Item Part No Description 1716532 DECAL, Danger, Auger 7075691 DECAL, 5200 Logo, Right Hand (Snapper) 7100786 DECAL, Top Cover RH (Snapper) 1717960 DECAL, Power-Mass (export models only) 1716533 DECAL, Danger, Discharge Chute 1733057 DECAL, Danger, Chute/Deflector 1709933 DECAL, C.E. (export models only)
- Page 20 Parts Manual for 520 Single Stage Snow Thrower Series 0 & 1 IT IS THE POLICY OF BRIGGS & STRATTON CORP. TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED Briggs &...
