M I-10KV
DESCRIPTION
The CIRCUTOR MI-10KV electronic megohmmeter is a versatile,
portable, user friendly, rugged instrument. It uses an efficient, well
experienced technology providing reliable, safe and accurate insulation
resistance measurements up to 2.000.000MΩ, with four test voltages:
1.000, 2.000, 5.000 and 10.000 V.
Due to its compact size and reduced weight, mechanical strength, self-
contained battery supply, this apparatus is particularly suitable for field
tests under severe environments. It is easily to be carried, very simple
to be operated and stands severe handling conditions including
frequent shocks, extreme temperatures, vibrations during transportation
through hard roads, long direct exposure to solar radiation, dust, sand
and other air-borne impurities, etc. Accuracy is not affected by all these
adverse conditions and it is still comparable with that of the best
laboratory instruments.
IMMUNITY AGAINST ELECTRIC AND MAGNETIC FIELDS
CIRCUTOR megohmmeters feature an effective filtering system that
improves immunity against electromagnetic disturbances and prevents
variations induced by industrial frequency fields.
OPERATOR'S SAFETY
Due to the high voltages involved, operator's safety is a must.
CIRCUTOR megohmmeters were designed considering this
outstanding aspect:
• ENCLOSURE: Molded in high dielectric strength plastic. There are no
conductive parts accessible to the operator with the exception of the
output terminals. This terminals are located in a hidden and protected
position on the enclosure.
