- Page 1 POWER QUALITY ANALYZER QNA-P / QNA-PV ( Cód. Q20713 / Q20731 QNA-P ) ( Cód. Q20830 / Q20831 QNA-PV ) USER MANUAL (M98155801-03 / 05A) CIRCUTOR S.A.
-
Page 2: Table Of Contents
QNA-P/PV MANUAL CONTENTS page 1.- BASIC INSTRUCTIONS..................2 1.1.- Checking the contents of your package ............2 1.2.- QNA-P/PV Models ..................2 1.3.- Safety warnings.................... 3 1.4.- Operating instructions .................. 3 2.- MAIN FEATURES ....................3 2.1.- Basic features ....................4 2.2.- Electrical features.................. -
Page 3: Basic Instructions
Q20731 Kit 1 QNA – P GPRS. (SIM not included) Q20712 Kit 2 QNA – P RS Q20732 Kit 2 QNA – P GPRS. (SIM not included) Q20830 QNA-PV RS (only voltage measurement) Q20831 QNA-PV GPRS (only voltage measurement) Page... -
Page 4: Safety Warnings
− • Connection to either 3 or 4-wire distribution systems. • Wide voltage supply range: 100-240 V c.a (QNA-P) / 100-400V c.a. ±30% (QNA-PV). • Internal battery allowing the instrument to continue recording in the event of voltage supply loss. -
Page 5: Basic Features
2.1.- Basic features The QNA-P/PV is an analyzer specifically designed to check electrical power supply quality in accordance with the IEC 61000-4-30 standard. In addition to the A.C. voltage inputs (insulated by transformers), the instrument is equipped with 4 inputs of 2V (clamps) . which allows the QNA-P/PV to also be used as a network analyzer. - Page 6 The different information recorded in the QNA-P/PV’s built in memory is distributed in four file types: *.STD files: This file contains all periodically recorded values (voltage, • current, frequency, power, energy, flicker, harmonic distortion, harmonic content, unbalance). *.EVE files: File containing all incidents referred to the QNA-P/PV itself (file •...
-
Page 7: Electrical Features
2.2.- Electrical features Using the QNA-P/PV as a recording instrument for evaluating electrical power supply quality means that the analyzer must have a high degree of protection against severe electrical conditions: • High-energy varistors absorbing surges to avoid any costly repairs. •... -
Page 8: Analysis Modes
3.- ANALYSIS MODES QNA-P/PV series analyzers can be used in different operating modes according to their setting. The most striking features of the analysers are: • Measurement and storage in memory of main power quality parameters (voltage values, flicker, harmonics and unbalance). •... -
Page 9: Installation & Start-Up
QNA-P/PV is equipped with a built in rotating memory for data collection; this means that once this memory is full, new values overwrite the oldest ones. Therefore, if no data is to be lost, data must be retrieved from the memory before the oldest values are overwritten. -
Page 10: Connection Terminal
5.1.- Connection terminal The QNA-P/PV analyzer may be installed in any three-phase distribution line with neutral conductor (4 wires) or without neutral conductor (3 wires). Measurements solely depend on the connection mode and the analyzer configuration The connection of an earth terminal is essential to ensure the efficiency of QNA-P/PV protection elements. -
Page 11: Communication Cables For Rj Connectors
5.1.1.- Communication cables for RJ connectors The most usual configurations for QNA-P/PV communication cables are as follows: • RS-232 connection to PC or to external modem: QNA-P/PV 1–DSR 5–GND 2–Rx 3–Tx 3–TX 2–Rx 4–CTS 7–RTS 5–RTS 8–CTS 6–GND 5–GND The RS-232 communication cables must always be disconnected to establish communication with a QNA-P/PV-GPRS/GSM via a mobile phone. -
Page 12: Starting The Qna-P/Pv Analyzer
Voltage: 100-240 V AC (QNA-P) Voltage: 100-400 ± 30% V c.a (QNA-PV). Frequency: 50... 60 Hz. 2) Ground terminal: The ground terminal of the analyzer must be connected to earth. If it is not connected some of the protective parts may not work properly. - Page 13 Points to consider: Voltage values flashing on the display is a sign that the analyzer is incorrectly installed or configured. Possible causes might be: − The analyzer detects an event: This can mean a real event in the network, or a wrong rated voltage setting where the set value does not match the actual network voltage.
-
Page 14: Connection Drawing For The Qna-P/Pv
5.3.- Connection drawing for the QNA-P/PV. Page... - Page 15 Page...
- Page 16 Page...
-
Page 17: The Qna-P/Pv Analyzer's Internal Battery
6.- THE QNA-P/PV ANALYZER’S INTERNAL BATTERY The analyzer has an internal battery to ensure power supply to the analyzer when any event occurs. This battery keeps the analyzer continuously powered for 2-4 hours in the event of the mains power supply being cut. This operating period after voltage supply loss is user-programmable in order to save the battery and to ensure that any possible intermittent voltage interruptions are detected. -
Page 18: Turning The Analyzer On
7.2.- Turning the analyzer on When the QNA-P/PV is turned on, the first screen appears with the analyzer’s identification: After some seconds, the display will show a screen displaying the three voltages measured by QNA-P/PV in each phase. Use the buttons to move through each available display screen. -
Page 19: Setting Up The Qna-P/Pv
Remarks The QNA-P/PV analyzer may indicate that it is incorrectly installed or configured. Possible causes might be: • Voltage values flashing on the display. Possible causes might be: − The analyzer detects an event: This can mean a real event in the network, or a wrong rated voltage setting where the set value does not match the actual network voltage.. -
Page 20: Features Of The Monitored Electrical Network
8.1.2.- Features of the monitored electrical network • Rated voltage: The rated voltage of the power system to be monitored by the QNA-P/PV analyzer. For a 3-wire configuration the line-to-line voltage must be set (ex. 400 V~), and for a 4-wire configuration the line-to-neutral voltage must be set (ex. - Page 21 Voltage swell hysteresis: A voltage swell hysteresis value can be defined at • a different value for the voltage swell event starting and finishing. Therefore, a voltage swell event starts when the voltage swell threshold is exceeded and ends when the voltage value is below the value defined by subtracting the voltage swell hysteresis value from the voltage swell threshold.
-
Page 22: Data To Take Into Account For The Periodical Data Recording Process
8.1.4.- Data to take into account for the periodical data recording process Some points to allow the user to precisely define the information to be used for the recording calculation procedure . Therefore, the user can define: Description of the measurement site: An identifying field to be filled in by •... -
Page 23: Selecting The Parameters To Be Recorded
8.2.- Selecting the parameters to be recorded The QNA-P/PV saves all quality parameter recordings in its internal memory. The different information recorded by the QNA-P/PV is distributed in three file types: 8.2.1.- Standard file (STD) The standard file (STD) is used to store all periodically recorded parameters. The following electrical parameters will be saved in the memory during the user-defined recording period: Parameter... -
Page 24: Events File (Evq)
Flicker: • Pst: The QNA-P/PV saves the Flicker value (Pst) obtained over the recording period. The Plt value will be calculated by the data analysis software in the PC. Harmonics: Harmonic distortion: The QNA-P/PV will calculate and record in the memory the value of the average voltage harmonic distortion detected in the monitored power system. -
Page 25: Incidents File (Eve)
8.2.3.- Incidents file (EVE) All incidents sent to the QNA-P/PV are automatically saved in this file, with an indication of the time and type of incident. The following incidents may be detected and recorded by the QNA-P/PV: Battery OFF: Indication of the time when QNA-P/PV stopped operating. This time depends on the value set by the user for the operating period after a voltage supply loss. -
Page 26: Harmonics Statistics File (H24)
8.2.4.- Harmonics statistics file (H24) A series of values to be susbsequently used by the PC’s software will be stored in this file. The software will calculate typical deviation, the statistical distribution curve and the effective values at 50%, 95% and 99% of each and every harmonic recorded by the QNA-P/PV . -
Page 27: Technical Specifications
9.- TECHNICAL SPECIFICATIONS Power supply: Supply voltage: Independent from the measuring circuit 100-240 V (QNA-P models) 100-400 V ±30% (QNA-PV models) Frequency: 50...60 Hz. Consumption: 16 VA – 8 W Working temperature: 0ºC to 50ºC Storage temperature: -20ºto 70ºC Auxiliary power supply:... - Page 28 Mechanical characteristics: Case: According to DIN 43859 Dimensions: According to DIN 43857 Weight: 6,7 Kg (QNA-P) / 5 Kg (QNA-PV) STANDARDS Quality : IEC 61000-4-30 Harmonics: IEC 61000-4-7 Flicker: IEC 61000-4-15 Other standards: EN 60664, EN 61010, EN 61036, VDE 110, UL 94...
-
Page 29: Safety Considerations
12.- TECHNICAL SERVICE For any information on the instrument’s performance or in the event of breakdown, please contact CIRCUTOR’s technical service. CIRCUTOR S.A. - After-sales service Vial Sant Jordi, s/n 08232 - Viladecavalls (BARCELONA - SPAIN) Tel - + 34 93 745 29 00... -
Page 30: Appendix: Installation And Start Up Of The Qna-Gsm/Gprs
A. Appendix: Installation and start up of the QNA-GSM/GPRS. Configure the QNA-P/PV analyzer before inserting the new SIM card N.B: The GSM line used must be capable of data transmission First the SIM on the phone line to be used must be configured to enable communication with the QNA-P/PV GSM/RS-232’s GSM modem,. - Page 31 Select options “SIM change” and “Enable use of PIN” Enter the PIN and PUK numbers for the SIM to be inserted. Accept the action and follow the steps shown by the software: a. Insert the new SIM card and then remove the RS-232 communication cable from the analyzer.
- Page 32 3. With the new card SIM inserted: 15) Remove the RS-232 cable from the analyzer. 16) Wait until the PC software issues a warning (About 60 s) 17) Reconnect the RS-232 communication cable to the QNA analyzer. 18) Check that the PC software notifies the results of the operation. The result may Successful: The QNA modem is ready to operate.
-
Page 33: Appendix: Installation And Start Up Of The Qna-Gprs
B. Appendix: Installation and start up of the QNA-GPRS. Steps to be followed when setting the QNA analyzer so that it sends recorded information via GPRS to an FTP server. 1- Apply power supply voltage to the QNA (it is important that when this is done, the RS-232 communications cable is not connected. -
Page 34: Appendix: Setting The Sms Alarms
C. Appendix: setting the SMS Alarms. The equipment may be set so that it sends an SMS message when a preset condition is met. Follow the steps below to activate and set the alarms: 1.- Connect the RS-232 communications cable to the equipment or set it to communicate via GSM 2.- Using the PowerVision software, enter the device’s general parameters and then press “SMS Alarms”... - Page 35 3. Select the type of alarm Drop down menu with the available types of alarm: Voltage V1, V2, V3, VIII Current I1, I2, I3, IIII Active power W1, W2, W3, WIII Capacitive power vaC1, vaC2, vaC3, vaCIII Inductive power vaL1, vaL2, vaL3, vaLIII PF1, PF2, PF3, PFIII Voltage THD VTHD1, VTHD2, VTHD3, VTHDIII...
- Page 36 Note: If the alarm time date is disabled, the alarm shall be active every day during the preset time slot. If the alarm time is disabled, the alarm will be active all the time. 9. Alarm message Received message text 10.
