Gree Electric Appliances, Inc. of Zhuhai will not assume responsibility for any personal injury or
property loss caused by improper installation, improper test running, and unnecessary repair or not
following the instructions of this manual.

2 Product Introduction

2.1 Names of Main Parts

One-to-one Cooling and Heating Mode Exchanger
One-to-two Cooling and Heating Mode Exchanger
One-to-more Cooling and Heating Mode Exchanger
GMV5 HR Heat Recovery Cooling and Heating Mode Exchanger
①
No.
Connection pipe of
Name
outdoor unit
Fig. 2.1.1
Fig. 2.1.2
Fig. 2.1.3
②
Drainage pipe
2
③
Connection pipe of
indoor unit
