Mylaps X2 Manual page 10

Cable (X2 RaceKey mount to 12 VDC power supply)
Type
Material
Color of housing
Number of contacts
Thread
Type of plug
Length
Outer diameter
Degree of protection (IP)
Environmental temperature
Environmental protection
EMC protection
Rate current
Nominal voltage
Contact material
Cable (X2 RaceKey mount to transponder)
Type
Material
Color of housing
Number of contacts
Thread
Type of plug
Length
Outer diameter
Degree of protection (IP)
Environmental temperature
Environmental protection
EMC protection
X2 transponder version 2018
Cable; Open end without connector
PUR halogen free
Black
4
M8
1x female (M8 female connector with snap-in joint,
straight, 4-poles)
1,5 m (59.1 inch)
4.5 mm (0.17 inch)
IP65, IP67 when mated
-40 - 90°C / -40 -
Oil and gasoline
No shielding
4A
60V
Gold plated pins
Cable with double-ended connectors
PUR halogen free
Black
4
M8
1x female (M8 female connector with snap-in joint,
straight, 4-poles)
1x male (M8 male connector with self-locking threaded
joint, straight, 4-poles)
2 m (78.7 inch)
4.5 mm (0.17 inch)
IP65, IP67 when mated
-40 - 90°C / -40 -
Oil and gasoline
No shielding
