P70, P72, and P170 Series Controls for Dual Pressure

Applications

Installation Instructions
Applications
The P70, P72, and P170 Controls for Dual Pressure Applications provide combined high and low pressure control
of compressors on commercial refrigeration and air conditioning applications.
IMPORTANT: Except for those models listed as refrigeration temperature limiting controls, use this P70, P72,
and P170 Series Controls for Dual Pressure Applications only as an operating control. Where failure or
malfunction of the P70, P72, or P170 Pressure Control could lead to personal injury or property damage to the
controlled equipment or other property, additional precautions must be designed into the control system.
Incorporate and maintain other devices, such as supervisory or alarm systems or safety or limit controls,
intended to warn of or protect against failure or malfunction of the P70, P72, or P170 Pressure Control.
P70S and P170S models have independently operated high and low pressure Single-Pole Double-Throw (SPDT)
switches that can be wired to satisfy a variety of control requirements. These adaptable controls have a high
pressure manual reset lockout mechanism that is convertible to automatic reset. See Table 1.
P70L, M, N, and P170L, M, N models have a Single-Pole Single-Throw (SPST) switch. Models are available with
automatic or manual reset lockout options. Models with manual reset are available with either high-side-only
manual reset, or low-side and high-side manual reset. (See Table 1 and Table 3.) Ammonia compatible models are
available (P70L and P70M only). See Table 2.
P72 models have a Double-Pole Single-Throw (DPST) switch with load-carrying contacts that can provide direct
control of 208/240 VAC, single-phase motors up to 3 hp, 480, and 600 VAC single-phase
non-compressor motors and 208/220 VAC, 3-phase motors up to 5 hp. See Table 3.
These controls are available in several pressure ranges and are compatible with most common refrigerants.
Ammonia-compatible models are also available (P70L and P70M only). See Table 2.
The MICRO-SET® option provides fine adjustment of the differential setting for precision pressure control of low
pressure applications.
Some models feature Limited Knob Adjustment, which restricts adjustment of the pressure settings and deters
over-adjustment or tampering. See Low Pressure Limited Knob Adjustment.
A Manual Reset Lockout option does not allow the pressure control to reset automatically after CUT OUT is
reached, and provides shutdown capability for unmonitored equipment. See Manual Reset Operation.
NEMA 1 enclosures are standard on most models. NEMA 3R enclosures are also available.
Table 1 through Table 2 list the standard models and features of P70, P72, and P170 controls for dual pressure
applications. These standard models are available through most authorized
Johnson Controls/PENN® distributors.
P70, P72, and P170 Series Controls for Dual Pressure Applications
Refer to the
QuickLIT website
Installation Instructions
1
Part No. 24-8607-0, Rev. J
Issued September 2018
for the most up-to-date version of this document.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P70 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Penn P70 Series

  • Page 1 Table 1 through Table 2 list the standard models and features of P70, P72, and P170 controls for dual pressure applications. These standard models are available through most authorized Johnson Controls/PENN® distributors. P70, P72, and P170 Series Controls for Dual Pressure Applications...
  • Page 2 Table 1: Standard Model P70, P72, and P170 MICRO-SET® Dual Pressure Controls for Non-Corrosive Refrigerants Model Code Switch Low Pressure Side High Pressure Side Pressure Limited Number Action psig (kPa) psig (kPa) Connector Knob Adjustment Range Differential Range Differential (Non- Adjustable) SPST 12 in.
  • Page 3 Table 3: Standard Model P70, P72, and P170 All Range Dual Pressure Controls for Non-Corrosive Refrigerants Model Code Switch Low Pressure Side High Pressure Side Pressure Limited Number Action psig (kPa) psig (kPa) Connector Knob Adjustment Range Differential Range Differential (Non- Adjustable) SPST...
  • Page 4 Figure 1: Dimensions for P70, P72, and P170 Dual Pressure Controls with NEMA 1 Enclosure, in. Figure 2: Dimensions for P70, P72, and P170 Dual Pressure Controls with NEMA 3R Enclosure, in. P70, P72, and P170 Series Controls for Dual Pressure Applications Installation Instructions...
  • Page 5 Mounting CAUTION: Risk of Property Damage. Mount the pressure control separately from the electrical cabinet and seal all electrical piping to prevent ammonia from migrating to electrical components. Where there may be exposure to ammonia, use only ammonia-compatible control modules and pressure connections. System shutdown due to improper adjustment may cause property damage.
  • Page 6 Wiring WARNING: Risk of Electric Shock. Disconnect or isolate all power supplies before making electrical connections. More than one disconnect or isolation may be required to completely de-energize equipment. Contact with components carrying hazardous voltage can cause electric shock and may result in severe personal injury or death. IMPORTANT: Use copper conductors only.
  • Page 7 Figure 6: Typical Wiring for DPST Switch (P72L, M, and N Models) Figure 7: Two SPDT Switches Wired as a Dual Pressure Control (P70S and P170S Figure 8: Two SPDT Switches Wired to Control Two Different Loads (P70S and P170S Models) P70, P72, and P170 Series Controls for Dual Pressure Applications Installation Instructions...
  • Page 8 Piping CAUTION: Risk of Environmental and Property Damage. Avoid sharp bends in the capillary tubes. Sharp bends can weaken or kink capillary tubes, which may result in refrigerant leaks or restrictions of flow. CAUTION: Risk of Environmental and Property Damage. Coil and secure excess capillary tubing away from contact with sharp or abrasive objects or surfaces.
  • Page 9 All-Range Controls (Low Side Only) The low side of All-Range controls displays the CUT IN and CUT OUT setpoints. Turn the range screw to adjust the cut in and cutout setpoints up or down simultaneously which maintains the set differential value. Turn the differential screw to adjust the cutout setpoint and change the differential value.
  • Page 10 Manual Reset Operation Pressure controls, with the Manual Reset option, lock out when they reach the cutout pressure setpoint and must be manually reset by the user to restart the controlled equipment. The manual reset mechanism is trip-free and cannot be overridden by blocking or tying the reset button down. On locked-out equipment, first determine and remedy the cause of the lockout before proceeding.
  • Page 11: Technical Specifications

    3. Place the spacer on the desired adjustment screw. All-Range controls (with Limited Knob Adjustment kits) have round and knurled adjustment screws. The spacer must be placed on the range screw. MICRO-SET® controls have square adjustment screws. Always place the spacer on the same adjustment screw as the knob. 4.
  • Page 12 P70, P72, and P170 Controls for Dual Pressure Applications (Part 1 of 2 ) Switch Action P70, P170: SPST or 4-Wire, 2-Circuit P70S, P170S: Two independent SPDT PENN® switches P72: DPST Pressure Connection P70, P72 Standard Models: various connections available (Styles 5, 13, 15, 34, 37) P170 Standard Models 1/4 in.
  • Page 13 CHINA www.penncontrols.com ® Johnson Controls and PENN are registered trademarks of Johnson Controls in the United States of America and/or other countries. All other trademarks used herein are the property of their respective owners. © Copyright 2018 by Johnson Controls. All rights reserved.
