1.
Overview
2.
3.
4.
Interconnectivity  :  Aux‐In,  Aux‐Out,  FX‐Loop,  and MIDI
5
Using SpecLab software (brief guide)
6
MIDI Implementation Chart
7.
Updating Firmware
Congratulation on your purchase of Specular Tempus!
Specular Tempus is a powerful reverb and delay effect processor in a compact pedal. Featuring 32
hand-crafted algorithms (13 reverbs, 13 delays, and 6 reverb & delay combinations), 8 presets. Stereo
in/out, tap-tempo, and extensive inter-connectivity. Using the SpecLab software (free download) users
get access to an extended set of parameters for deep-editing of the algorithms.

Preset System

There are a total of 32 presets, organized in 16 banks, where each bank contains two patches :
A and B.
Bank :
1
Patch :
A / B
Changing banks (1 though 4) and calling the patches are accomplished using the two on-board foot-
switches (see Chapter 2 for details).
Table of Contents
* Important - must read *
Chapter 1 - OVERVIEW
2
3
4
A / B
A / B
A / B

User Manual

S P E C U L A R T E M P U S
R E V E R B - D E L A Y
5
A / B
Bank 5 through 16 are accessible
Only via MIDI (PC# 8 though 31)
2
3 - 13
14 - 17
18 - 25
26 - 27
28 - 29
30
1
16
A / B
2 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPECULAR TEMPUS and is the answer not in the manual?

Questions and answers

Related Manuals for GFI System SPECULAR TEMPUS

Summary of Contents for GFI System SPECULAR TEMPUS

  • Page 1: User Manual

    Chapter 1 - OVERVIEW Congratulation on your purchase of Specular Tempus! Specular Tempus is a powerful reverb and delay effect processor in a compact pedal. Featuring 32 hand-crafted algorithms (13 reverbs, 13 delays, and 6 reverb & delay combinations), 8 presets. Stereo in/out, tap-tempo, and extensive inter-connectivity.
  • Page 2 Chapter 2 - OPERATION Illuminated knobs indicate the preset Bank number : 1 - 2 - 3 - 4 Bank-1 Bank-2 Bank-3 Bank-4 >> Clear Sky DL: Digital Footswitch A Footswitch B LED A LED B View / Edit button ...
  • Page 3 2.1 Bank-Up  Press A and B simultaneously (do not hold). Patch A title A >> Long Tail B >> Dark Verb Patch B title < The display will show the titles of both patch A and patch B > Note : - This operation can also be done using an external switch box (see Chapter 4).
  • Page 4 2.5 Auto Swell  Press A and B simultaneously, and hold. The parameter controlled by one of the four knobs** gradually sweeps from its current value to the maximum value (as if someone slowly turns the knob all the way up). current value The value will remain at maximum as long as you hold the footswitches down.
  • Page 5 3. Activate the algorithm.  Tap the View / Edit button again DL: TRANSPOSER algo activated The algorithm is now activated. You can save the selected algorithm as preset using the normal procedure for saving preset (see section 2.3). The preset’s title will be automatically set to the name of the algorithm. Preset Title >>...
  • Page 6 However you may change it on the fly using the TIME knob. Local / Global tempo The tempo of the Delay algorithms in Specular Tempus can be set to be local or global. Local means the delay time is set to the tempo as was saved in the preset.
  • Page 7 2.9 Global Configuration The pedal has a number of features and functionalities that are global (apply to all presets), these include :  Aux-In switches (external switch box) assignment (see section 4.1 for details).  Midi Channel : 1 to 16 ...
  • Page 8 The algorithms from our award-winning Specular Reverb V2 pedal have all been ported to Specu- lar Tempus, improved and expanded with additional parameters and features for deeper tweaking. Some of those algorithms appear with different names in Specular Tempus. Specular Reverb V2 ...
  • Page 9 Chapter 4 - INTERCONNECTIVITY Specular Tempus has been designed with the need to interconnect with the outside world in mind. It sports no less then 4 interfaces : Aux-In, Aux-Out, MIDI In, and Effects Loop. We will now explain what these interfaces do.
  • Page 10 External switch box (3-buttons) Ring Tip + Ring Wiring : stereo cable Aux-In External switch box (2-buttons) Ring Wiring : stereo cable External switch box (1-button) * Note that you still need to use a stereo cable even Wiring : when using a single-button switchbox.
  • Page 11  Bank-Up  Bank-Down  Tap-Tempo These three are self-explanatory and require no further elaboration.  Favorite Preset Call This function allows you to set any one of the available 8 presets as a favorite preset which you can quickly call with just a single footswitch tap, regardless of which preset you are currently in. For example you assign preset 4A (Bank-4, patch A) as your favorite, then no matter which preset you are currently in you can always call preset 4A by tapping on the switch that you’ve assign for this function, no need to change banks and stuff.
  • Page 12 4.3 Aux-Out This interface provides a switch contact that allows Specular Tempus to control another piece of gear. The switch contact can be configured as : 1. Opened / Closed (latching) switch. An opened / closed switch can be used to control external gears that has the facility for exter- nal switch control.
  • Page 13 The effects loop allows you to insert an external effect processor into the feedback loop of the re- verb or delay algorithms in Specular Tempus. For example, inserting a phaser pedal will add a phaser effect to the repeats of a delay algorithm.
  • Page 14 Reading stored preset from Specular Tempus (1) Choose the desired preset location (2) Click ‘READ’ Preset Pages The 32 preset location is organized within 4 pages, each page contains 4 banks, and each bank contains 2 patches (A and B).
  • Page 15 25  any  MIDI Channel Specular Tempus is pre-programmed to use MIDI channel 15. You can change the channel number to any number from 1 through 16 using the editor software or from the pedal itself (see section 2.9). Chapter 7 - UPDATING FIRMWARE 1.

  • Page 16: Specifications

      Effects Loop.   Bright LEDs and LCD display. You can find many more information here : http://www.gfisystem.com/specular-tempus--faq.html This product is designed and manufactured by : Email : info@gfisystem.com (inquiry) gfisys@gmail.com (support) Web : www.gfisystem.com GFI System Jakarta, Indonesia.
