Page 1: Table Of Contents
User Manual O R C A U S E R M A N U A L DELAY Table of Contents Inputs Page 1 Outputs Expression Input Tap-Tempo Input Knobs and Buttons Footswitches and LEDs Saving Presets Options Global Settings 10 Expression / Ramping Setup 11 Factory Reset... -
Page 2: Inputs
Set to STEREO when using stereo input. 2. Outputs Orca may be used for mono output or stereo outputs. For mono output use a standard mono (TS) patch cable and for stereo outputs use a stereo (TRS) cable. If the stereo output signals are fed to an equipment that has separate Left and Right channel input jacks you will need to use a splitter cable like the one pictured above. -
Page 3: Expression Input
TS cable & plug Auto detection Upon power up Orca will automatically detect the presence (or absence) of an expression pedal or a tap-tempo pedal. Therefore, after plugging/unplugging the external gear you need to reboot Orca to let it detect the changes. -
Page 4: Knobs And Buttons
User Manual O R C A DELAY 5. Knobs and Buttons Every knob is also a button. The following operations can be done on each knob : TURN PUSH or TAP HOLD TWIST ( hold and turn ) Here’s a summary of what each knob and each switch does, this is just a quick reference, more detailed explanation will be given in the next chapter. -
Page 5: Footswitches And Leds
User Manual O R C A DELAY 6. Footswitches and LEDs TEMPO LED ENGAGE / RAMP SWITCH A/B - TAP SWITCH -> bypass / engage TAP (at least 2x) -> set a new tempo. HOLD (when bypassed) for > 500 ms ->... -
Page 6: Saving Presets
User Manual O R C A DELAY 7. Saving Presets Press and Hold both buttons Save to: ~ release the hold when the screen reads: <-> Tap the left button to save to preset A, or Tap the right button to save to preset B. If, after entering the Preset-Save scene, you change your mind and would like to exit without saving any changes, you can do so by : ... -
Page 7: Global Settings
User Manual O R C A DELAY 9. Global Setting Press and hold the MODES button for 2 secs to enter Globals menu. Use the MODES knob/button to navigate around the menu. Globals 1. Input Mono : input signal is mono Stereo : input signal is stereo. -
Page 8: Expression / Ramping Setup
User Manual O R C A DELAY 10. Expression / Ramping Setup Up to 3 primary parameters may be mapped to the expression pedal / ramping function. Push the knob’s button to toggle the parameter mapping. PUSH once Exp Pedl mapped PUSH once Exp Pedl... -
Page 9: Factory Reset
Expression pedal and tap-tempo input. Momentary action supported. Visit the product page at our website for more demo videos, sound clips, FAQs, and updates. This product is designed and manufactured by : Email : info@gfisystem.com (inquiry) gfisys@gmail.com (support) Web : www.gfisystem.com GFI System...
