9.2 Technical Specification

Tuner & Channel
No. of Tuners
Frequency
Range
Signal Level
LNB Power
LNB Tone
Switch
DiSEqC Control
MPEG
Transport
Stream
Profile Level
Input Rate
Aspect Ratio
Video
Resolution
Audio Decoding
Audio Mode
Sampling
Power Supply
Input Voltage
Power
1
950 MHz to 2150 MHz
-25 to -65 dBm
13V/18V/VOFF, Imax = 400mA
22KHz+/-2KHz, 0.6Vpp+/-0.2V
Version DiSEq C 1.0/1.1/1.2/1.3(USALS)Compatible,
Tone burst A/B
MPEG-2 ISO/IEC 13818Transport stream specification
MPEG1,MPEG-2 MP@ML,H.264, VC1, DV, DivX, and
MPEG4
80 Mbps for MPEG Transport Stream and 25 Mbps for
DV streams
4:3, 16:9
576i, 576p, 480i, 480p, 720p50, 720p60, 1080i.1080P
MPEG-2 layer I and II (Music cam),MPEG4 AAC and
MPEG4 AAC-HE (AAC+),Dolby Digital (AC-3) with bit
rates up to 640 K bits /s, LPCM up to 48 KHz,MP3.
Single channel/Dual channel/Joint stereo/Stereo
32, 44.1 and 48 KHz
AC 100 ~240V, 50/60Hz
Max. 25 W
