Page 1: User Manual
User Manual Digital Satellite Receiver 1000 English 1/2010 jp... -
Page 2: Table Of Contents
Contents Safety precautions ..........................3 Environment protection .......................... 5 General Information..........................6 Unpacking ................................6 Front Panel ................................7 Remote Control ..............................8 Installation .............................. 9 Connecting to TV using SCART support ........................9 Main page ............................. 10 Installation ................................11 Antenna Setting .............................. -
Page 3: Safety Precautions
Safety precautions CAUTION: The lightning flash with Warning: The exclamation point within arrowhead symbol, To reduce the risk of electric an equilateral triangle is within equilateral shock, don't open the cabinet. intended to alert the user to triangle, is intended to Refer servicing to qualified important operating... - Page 4 Attachments: Never add any attachments and/or equipment without the manufacturer consent; as such additions may result in the risk of fire, electric shock, or other personal injury. Locating: Slots and openings in the cabinet are provided for ventilation to protect it from overheating.
-
Page 5: Environment Protection
Environment protection Attention! Your product Is marked with this symbol. It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collection system for these products. Information on Disposal for Users (private households) in the European Union Used electrical and electronic equipment must be treated separately and In accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment. -
Page 6: General Information
General Information A Digital Satellite Receiver is a convenient product that allows you to view a variety of programs provided through satellite. This user’s guide covers the installation of the DSR and the necessary steps to implement various features. This also explains special features available only in this DSR in detail, which will allow you to make full of these feature. -
Page 7: Front Panel
Front Panel Funktion 1. The red LED Lights up when the receiver has been standby on. 2. The green LED Lights up when the receiver has been working. 3. The yellow LED Lights up when the channel has been locked. 4. -
Page 8: Remote Control
Switches back to previous channel. SCAN Optional buttons. Those functions are available ZOOM for other receiver – Opticum 1050 TEXT Warning! Because of requirement of conformity with directives of energy saving, receiver supports function of automatic turning into standby mode after 3 hours from last use... -
Page 9: Installation
Installation This section explains the installation of DSR-SERIES. Refer to the manuals supplied with the equipment for the installation of outdoor equipment such as the dish antenna. When adding new equipment, be sure to refer to the related parts of the manual for the installation. -
Page 10: Main Page
Main page While viewing channels, press MENU key on the remote control, the Main Page box will be displayed on the Left side of the screen. If you do not want this Main Page, press EXIT key. Main Page consist of 7 menus as below: •... -
Page 11: Installation
Installation DSR-SERIES has install Wizard system which allows users to set up the DSR-SERIES setting only minimum configuration for viewing channels. This “installation” is for the advanced user or installer to set up in detail or Up-grade the DSR-SERIES as their favorite way for advanced function. -
Page 12: Satellite Search
DiSEqC 1.2 User can enable and change the settings of the DiSEqC1.2 motor. The motor settings include: • Enable or Disable the DiSEqC1.2 • Enable or Disable the software limits of the motor movement. Recalculate Limits activates the default positions and limits of the motor, thereby the user set previous values will be erased. -
Page 13: Manual Search
Manual Search In the menu ,set the Search Parameters (Frequency, Symbol Rate, Polarization, etc.) to manually find the services that you have select in the transport. The bars at the bottom of the menu show signal power and signal quality of the entered parameters. You can select the value of some items by the ◄... -
Page 14: Reset Default
Reset Default When enter the menu, Press the OK button to confirm and all searched channels will be erased. Figure 10 Channel Manager This menu contains of 3 major sub-menus as below (Figure11); • Modify Channel • Delete Channel • Move Channel •... -
Page 15: Delete Channel
Delete Channel In this menu, you can delete some services by use the ▲▼ ◄► buttons, Press the OK buttons to confirm as below (Figure13) and EXIT buttons to exit. Figure 13 Move Channel In this menu, you can move some channels by use the ▲▼... -
Page 16: Add Favorite
Add Favorite In this menu, you can add some channels to favorite channels by use the ▲▼ ◄►buttons, Press the OK, Menu buttons to confirm as below (Figure16) and EXIT buttons to exit. Figure 16 Sort Channel In this menu, you can use the ▲▼ ◄► buttons to sort services by A~Z, Z~A etc., and move, Lock, Skip Channels, Press the OK, Menu buttons to confirm as below (Figure17) and EXIT buttons to exit. -
Page 17: Video Output
Video Output In this menu, you can use the ◄► buttons to select TV system to Auto, NTSC, PAL, Press the OK buttons to confirm as below (Figure19) and EXIT buttons to exit. Figure 19 Switch Mode In this menu, you can use the ◄► buttons to select change channel mode for Direct, Fade, Curtain, Press the OK buttons to confirm as below (Figure20) and EXIT buttons to exit. -
Page 18: Clock Setup
Clock Setup In this menu, you can setup clock and time zone, Press the OK buttons to confirm as below (Figure 23) and EXIT buttons to exit. Figure 22 Language Setting In this menu, you can use the ◄► buttons to select menu language, Press the OK buttons to confirm as below (Figure 24) and EXIT buttons to exit. -
Page 19: Game
Game In this menu, you can select two game, Press the OK buttons to confirm as below (Figure 25) and EXIT buttons to exit. Figure 24 Quick Select In this view, Press OK then SAT(Red) key buttons to select the item, and press OK button to select satellite you want, and press OK button to select the channels you want The contents of those items are following: Figure 25/1... -
Page 20: System Update
System Update In this menu, you can upgrade new software from main receiver, Press the OK buttons to confirm as below (Figure 28) and EXIT buttons to exit. a) Connect the RS232 twisted cable between Source and Destination targets. b) Standby and press the CH Up key in Front panel of the Source Target to invoke Loader upload menu. -
Page 21: Trouble Shooting
Trouble Shooting If you suspect there is a fault with your receiver, please check the following trouble shooting guide before calling authorized service agent. Warning! Under no circumstances attempt to repair the receiver yourself. Tampering with the receiver may result in fatal electric shock and will invalidate your warranty. Symptom Possible cause Receiver is in Standby mode. -
Page 22: Product Specification
Product Specification Demodulator Waveform QPSK demodulation and FEC decoding in accordance with DVB Symbol rate 2<Rs<40 Msps Video-Decoder Data rate up to 15 Mbits/s Audio-Decoder Decompression MPEG-2 Layer I and II Outputs Stereo, Dual Mono, Joint Stereo, Mono System Haier 2301E Clock frequency 108 MHz Flash memory... -
Page 23: Declaration Of Conformity
The manufacturer herewith declares the conformity of that product with the following directives and standards: Low Voltage Directive 2006/95/EG EN 60065:2002+A1:2006 EMC Directive 2004/108/EG EN 55 013:2001+A1:2003+A2:2006 EN 55 020:2007 EN 61 000-3-2:2006 EN 61 000-3-3:1995+A1:2001+A2:2005 Model: Digital Satellite Receiver DVB-S...
