D8128D Overview

2.1

Specifications

Operating Voltage
Current
Sensor Loop Response Time
Cabling
Resistance
Environmental
2.2

Module Description

The D8128D OctoPOPIT Module combines the functions of the D8125 POPEX module and the D8127/D9127
POPIT modules to provide eight off-board points in a single module. You can wire both D8128D OctoPOPIT and
D8125 POPEX modules in parallel to the ZONEX Bus terminals on the same panel.
Review the Power Outputs section of your panel's Operation and Installation Manual to be sure you provide
enough power for the OctoPOPITs and other powered devices you wish to connect to your system.
The D8128D is designed for use with the Radionics' panels shown in the table below. (Also shown are previously
manufactured D8128 OctoPOPIT Modules.)
OctoPOPIT
D8128A
D8128B
D8128C
D8128D
* D9124 w/ D9112LTB uses D8128A, D9124 w/ D9112LTB-EX uses D8128D.
Note: As shown in the table above, D8128A OctoPOPITs cannot be used on the new D7212, D7412, D9112, or D9412
Control Communicators. However, D8128D OctoPOPITs may be used and intermixed with D8128A OctoPOPITs
on the D7212B1 and D9112B1 Control Communicators.
