Figure 3: Wiring The D8128D To The Panel With A D8125 Popex Module - Radionics D8128D Installation Instructions Manual

D8128D
Installation
28
27
26
25
24
23
TERMINAL 9 ON
D7212 / D7412
TERMINAL 3 ON
D7212 / D7412

Figure 3: Wiring the D8128D to the Panel with a D8125 POPEX Module

41343D
ZONEX BUS 1
Switch 1 CLOSED
(Points 9 - 72)
Bus 1
SENSOR
LOOPS
ZONEX BUS 2
Switch 1 CLOSED
(Points 129 - 192)
Bus 2
SENSOR
LOOPS
D8125
POPEX
(-)
(-)
(+)
(+)
GND
OUT
IN
AUX
D8128D OctoPOPIT Module Installation Instructions
Page 12
Bus 1 continued
SENSOR
LOOPS
1 2 3 4 5 6 7 8
P O I N T S
Bus 2 continued
SENSOR
LOOPS
1 2 3 4 5 6 7 8
P O I N T S P O I N T S
D9127U
DAT
LOO
- - + + -
+
POSITIVE (+)
NEGATIVE (-)
ZONE EXPANSION LOOP
ZONEX BUS 1
Switch 1 OPEN
(Points 73 - 127)
1 2 3 4 5 6 7 8
P O I N T S
ZONEX BUS 2
Switch 1 OPEN
(Points 193 - 247)
1 2 3 4 5 6 7 8
P O I N T S P O I N T S
© 2001 Radionics
