3.3.1

Connecting the D8128D to the Control/Communicator using the Terminal Strip

When connecting the D8128D to a D9412, D9112, D7412, or D7212 via the OctoPOPIT's terminal strip the
following connections must be made:
D8128D
Common
Out
In
+12 V
© 2001 Radionics
D9412/D9112
Terminal 23
Zonex 1 = Terminal 27
Zonex 2 = Terminal 25
Zonex 1 = Terminal 28
Zonex 2= Terminal 26
Terminal 24

Table 4: Terminal Strip Connections

D8128D OctoPOPIT Module Installation Instructions
Page 11
D8128D D7412/D7212
Common Terminal 9
In Terminal 28
Out Terminal 27
+12 V Terminal 3
