TECHNICAL SPEC
Standards
Number of Zones
Number of alarm Lines
Mains Input Voltage
Standby Duration
System operating Voltage
Indicators
Fire
Fault
Power
Fault Indications
Zones
Alarms
Power
Earth Fault
System Fault
End of Line Elements
Zones
Alarms
Maximum No of detectors per zone
Maximum Alarm Load
Auxiliary DC Output
Auxiliary Fault Output
Remote Signal Output
Standby Power source (Battery)
Battery Recharge Period
Terminal Connector Capacity
Dimensions
Panel Weight (Mass)
Panel operating temperature
Design to comply with EN54 Part 4 1996 and Part 2
1996
Electromagnetic Compatibility EN 50130-4 1996
Alarm Systems Part 4 EN50081-1 1992
EN61000-2-2-1994
4(MF400)
2
240Vac +10%-15%
24Hr
24Vdc Nominal
High intensity red Light Emitting Indicators (LED)
High intensity yellow LED's
High intensity green LED
Open and short circuit, detector removed
Open and short circuit
Mains fail, battery fault, battery charge fault. All fuses are
monitored.
Any Earth connection to low voltage system
Micro contoller fault
22kohm
22kohm
20 (24V-30µA each)
750mA 24Vdc
32mA 24Vdc (Up to 100mA at the expense of Alarm Load)
24Vdc pull to 0V. Maximum 10mA
24Vdc pull to 0V. Maximum 10mA
One Valve Regulated (Absorption Type) Lead Acid
12V Battery Recommenced replacement period 4
years. Capacity 4AH (24Hr Standby) 7AH
(72Hr standby) Max current draw is 3A resistive.
48Hrs
0.5mm 2 to 2.5mm 2
300mm X 300mm X 74mm
24Hr 4.8kg, 72Hr 6.0Kg
-5°C to +40°C Humidity 75% (Non Condensing)
PAGE 11
2(MF200)
