ZFR100 Recording System Owner's Manual
Specifications

ZFR100 Specifcations

Dynamic Range
Distortion
Frequency response
Microphone input level
Microphone Power
High Pass filter
High Pass Filter frequency
Output file type
Output resolution
Output sample rate
Time Code Type
Time code rate
Size
106 dB
Less than .001%
20 Hz to 20 KHz
-60 dB to –24 dB
3.3 VDC @10 mA max
18dB per octave
30Hz to 220Hz
.WAV
16- or 24- bits selectable
32 KHz, 44100 KHz, 48000 KHz, 48048 KHz
SMPTE
23.96, 24,25, 29.97, 29.97DF, 30, 30DF
3.0-in. x 2.3-in. x 0.75-in. (76 mm x 58 mm x 19 mm)
