Code Levels

4

Menu Overview

© Danfoss | DCS (ADAP-KOOL®) | 2018.12
All inputs and changes are protected by a
four-digit numeric code (= password) against
unauthorised intervention according to the
regulations of all national and international
standards for gas warning systems. The menu
windows of status messages and measuring
values are visible without entering a code.
The access to the protected features is cancelled
automatically if no button is pushed within 15
minutes.
The service technician access code to the
protected features is '1234'
Menu operation is done via a clear, intuitive and
logical menu structure. The operating menu
contains the following levels:
• Starting menu with indication of the device
type if no Measuring Point is registered,
otherwise scrolling display of the gas
concentrations of all registered sensors in
5-second intervals. If alarms are active, only the
values of the sensors currently in alarm status
are displayed.
• Main menu
• 5 sub menus under "Installation and
Calibration"
Power On Time of the basic device
Power On Time
Second counter counts down, when communication display <> basic
19s
device is OK. In case of communication error the count-down will stop.
Seconds indicator = 0
Danfoss
DGS
After about 2 seconds
"Warm-up Time" is displayed. As soon as the sensor warm-up time has
D1 CO2 ppm
expired, the measured value is displayed = measuring mode.
Warm-up Time
RS8KD102 | 7
