Language

4.5.3

LCD Function Check

4.6

Measuring Point Parameters

4.6.1

Alarm limits

4.6.2

Alarm delay

12 | RS8KD102
Language
English
Selection of the menu language (password
protected)
Symbol Description
English Language
Function for testing the LCD function (password protected)
All LEDs light up for about two seconds. The backlight is
yellow. (Green and red are activated at the same time). All
points are displayed on the LCD
LCD Function
check ?
Reading and changing of the parameters for each
measuring point.
Selection of measuring point (1 – X)
MP Parameters
For each measuring point two alarm thresholds
are available for free definition. If the gas
concentration is higher than the set alarm
threshold, the associated alarm is activated. If the
gas concentration falls below the alarm threshold
inclusive hysteresis the alarm is reset again.
The hysteresis of both alarm is 5% of the default
alarm threshold (e.g. with 5000pmm this
corresponds to 250ppm)
For setting the alarm delay for Critical and
Warning alarms
Symbol Description
0 sec. Delay Alarm
Default Function
English
USA English
English German
French
Spanish
MP 1
Active
Default Function
Gas concentration > alarm threshold + set time = Alarm ON
0 sec
Gas concentration < alarm threshold – hysteresis = Alarm OFF
© Danfoss | DCS (ADAP-KOOL®) | 2018.12
Warning limit
C 5000 ppm
Critical limit
C 5000 ppm
Delay Alarm ON
0 s
