Danfoss VLT 2000 Series Manual page 105

Operation and display
000 LANGUAGE S )
ENGLISH
001 MENU SETUP S )
SETUP 1
002 MENU SET COPY
DO NOT COPY
003 LOCAL/REMOTE S )
REMOTE
004 LOCAL S )
005 VALUE AT MAX S )
1000
S
006 LOCAL RESET )
ENABLE
007 LOC START/STOP S )
ENABLE
008 LOCAL FWD/REV S )
DISABLE
009 LOCAL JOG S )
ENABLE
010 LOC REFERENCE S )
ENABLE
013 DATACHG.LOCK
NOT LOCKED
Load and motor
101 SPEED CONTROL 2, S )
SLIP COMP
S
102 CURRENT LIMIT )
PROGRAM SET
103 MOTOR POWER 2 )
NOM. SIZE
104 MOTOR VOLTAGE 2 )
Depending on unit
105 MOTOR FREQ 2 )
50 Hz
107 MOTOR CURRENT 2,S )
Depending on unit
108 MOTOR MAG.AMP. 2,S )
Depending on unit
109 START VOLTAGE 2,S )
Depending on unit
110 START COMP 2,S )
0
2,S
111 U/F RATIO )
Depending on unit
2,S
112 SLIP COMPENSATION
Depending on unit
114 FEEDBACK TYPE S )
CURRENT
119 FEEDFWD FACTR 2,S )
100%
120 CONTRL RANGE 2,S )
100%
121 PROPRT/L GAIN 2,S )
0.01
122 INTEGRAL TIME 2,S )
OFF
125 FEEDBACK SCALE
100%
MG.20.B6.02 – VLT is a registered Danfoss trademark
References
200 FREQ RANGE
120 Hz
201 MIN. FREQUENCY
0
202 MAX. FREQUENCY
50 Hz
203 JOG FREQUENCY
10 Hz
204 DIG. REF. TYPE
SUM
205 DIGITAL REF. 1
0
206 DIGITAL REF. 2
0
207 DIGITAL REF. 3
0
208 DIGITAL REF. 4
0
209 CURRENT LIMIT
Depending on unit
210 LOW FREQ WARN
0 Hz
211 HI FREQ WARN
120 Hz (from 200)
213 HI CURR WARN
I (from 209)
VLT,MAX
215 RAMP UP TIME 1
5 s
216 RAMP DOWN TIME 1
5 s
218 ALT: DOWN RAMP 1
1 s
224 CARRIER FREQ.
4.5 KhZ
230 SPEED UP/DOWN
DISABLE
Functions and timers
300 BRAKE OPTION
NOT APPLIED
306 DC-BRAKE TIME
0 s
307 DC-BRK FREQ
1 Hz
308 DC-BRK VOLTAGE
)
10 V
309 RESET MODE
MANUAL
310 TRIP DLY@C.LIM
INFINITE
315 MOTOR THERMAL
PROTECT-OFF
VLT ® 2000 Series
Inputs and outputs
402 INPUT 18
2
)
START
403 INPUT 19
2,S )
REVERSING
404 INPUT 27
2,S )
MTR.COAST not
405 INPUT 29
2,S )
JOG
S ) 408 LOG OUTPUT 46
UNIT READY
2,S ) 409 RELAY OUT 01
UNIT READY
2,S )
411 ANALOG REF TYPE
LINEAR
412 INPUT #53
2,S
)
0 - 10 VDC
413 INPUT #60
2,S
)
0-20 mA
2,S )
Serial data interface
500 ADDRESS
2,S )
01
501 BAUD RATE
2,S )
1200 K
502 DATA READ-OUT
2,S )
REFERENCE%
503 COASTING
2,S
)
LOGICAL OR
504 Q-STOP
2,S
)
LOGICAL OR
505 DC-BRAKE
2,s
)
LOGICAL OR
506 START
2,S
)
LOGICAL OR
507 DIRECTION
S )
DIGITAL
508 RESET
LOGICAL OR
509 SETUP SELECT
S ) LOGICAL OR
510 SPEED SELECT
LOGICAL OR
2,S )
511 BUS JOG 1
10 Hz
2,S )
514 BUS BIT 4
QUICK STOP
2,S )
516 BUS REFERENCE
0
S
)
517 STORE DATA
OFF
S )
Service and display
2,S )
606 TOTAL OP HRS.
607 RUNNING HRS.
608 NO. POWERUPS
609 NO. OVERTEMPS
610 NO. OVERVOLTS
2 ) Can be changed in both setups
S
) Can be changed i Start mode
(running motor)
S )
S )
S
)
S )
2,S )
2,S )
2,S )
2,S )
2,S )
S )
S )
S )
S )
S )
S
)
S )
S
)
S )
S )
S )
S
)
S )
105
