Step1: Initial Command
As the information showed on your screen, please enter these commands below to
start your test.
Command: 1 Wi-Fi testing mode
Step2: Generate 802.11 b/g/n Packet
(1)Command: 22 1 12 1
22: Initial transmit power in the antenna
1: Set the wanted channel (1~11 for B/G/N mode)
12: Set the wanted power, typically G mode: 25.05 dBm/ B mode: 21.26 dBm
1: Set the mode, 1_G mode & N mode , 0_ B mode
(2)Command: 112 0 (only for N mode)
112: N mode HT20/40.
0: for HT20/40. 0_HT20, 1_HT40
(3)Command: 25 1 13
25: Set duty cycle, packet mode.
1: Data rate enable
13: Data rate set up
A mode &B mode & G mode
1Mbps
5.5Mbps
11Mbps
1
3
4
N mode
MCS0
MCS1
15
16
After you type above command, you can measure the 802.11b/g/n packet by your RF
test instrument (exp: Agilent 4010, IQview...).
(4) Command: 25 0
Stop transmitting packet signal.
6Mbps
9Mbps
6
7
MCS2
MCS3
17
18
12Mbps
18Mbps
24Mbps
8
9
10
MCS4
MCS5
19
20
36Mbps
48Mbps
11
12
MCS6
MCS7
21
22
54Mbps
13
MCS8
23
