COMPONENT LIST

5
1. HAND GRIP AREA
2. ON/ OFF SWITCH
3.
AUXILLARY HANDLE
4. BEVEL SCALE
5. PARALLEL GUIDE LOCKING SCREW
6. BEVEL LOCK BUTTON
7. FIXED GUARD
8. SAW BLADE
9. LOWER BLADE GUARD
10. LOWER GUARD LEVER
11. BASE PLATE
12. DUST TUBE
13. CHARGER*
BATTERY PACK* -
14.
ON PAGE 13 FOR BATTERY INFORMATION
BATTERY TEST BUTTON AND
15.
CHARGE INDICATOR*
*If applicable
12
3
4
6
PLEASE REFER TO TABLE
2
1
9
8
7
12
11
10
13
Battery size shown for
illustrative purposes only
Instruction & User Manual
14
15
JCB-18CS
