- Page 1 POWER TOOL INSTRUCTION & USER MANUAL JCB-MS-254SB-L Original Instructions IM-MS-254SB-L-EN Iss: 09/2019...
- Page 2 The month and year of manufacture can be found within the product serial number e.g. MMYYPPPAXXXXX. Where production month (MM) and production year (YY) are included. JCB-MS-254SB Designation of the tool (MS – Mitre Saw, 254SB – 254mm single bevel sliding) JCB-MS-254SB-L...
-
Page 3: Table Of Contents
Mitre cut 0°- 45° and turntable 0°- 45° Limiting the cutting depth Sawdust bag Changing the saw blade MAINTENANCE AND ELECTRICAL CONNECTION 23 Maintenance Electrical connection Transport Storage DISPOSAL AND RECYCLING WARRANTY STATEMENT GENERAL CERTIFICATE OF CONFORMITY JCB-MS-254SB-L Instruction & User Manual... -
Page 4: General Safety Instructions
– There is an increased risk of electric shock if personal injuries. your body is earthed or grounded. JCB-MS-254SB-L Instruction & User Manual... - Page 5 Power tool use and care intended for the particular type of Do not force the power tool. Use power tool, taking into account the the correct power tool for your working conditions and the work to be application. performed. JCB-MS-254SB-L Instruction & User Manual...
-
Page 6: Safety Instructions For Mitre Saws
There should be no nails the fence and the table. Do not feed or foreign objects in the workpiece. the workpiece into the blade or cut “freehand” in any way. JCB-MS-254SB-L Instruction & User Manual... - Page 7 – Reaching with your hand near the coasting Do not use another person as a blade is dangerous. substitute for a table extension or as additional support. JCB-MS-254SB-L Instruction & User Manual...
-
Page 8: Safety Instructions For The Handling Of Saw Blades
Prior to use, make sure that the saw blades meets the technical requirements of this electric tool and is properly fastened. Only use the supplied saw blade for cutting wood and plastic, never for the processing of metals. JCB-MS-254SB-L Instruction & User Manual... - Page 9 The laser may not be replaced with a • different type of laser. Repairs of the laser may only be carried out • by the laser manufacturer or an authorised representative JCB-MS-254SB-L Instruction & User Manual...
-
Page 10: Component List
14. Turn table Moving blade guard 15. Fixed saw table Saw blade 16. Stop rail Clamping device 16a Extension block Workpiece support 16b Set screw Locking screw for workpiece support 17. Sawdust bag 10. Table insert JCB-MS-254SB-L Instruction & User Manual... - Page 11 23. Fastening bolt 33. Laser 24. Screw for cutting depth limiter 34. ON/OFF switch for laser 25. Stop for cutting depth limiter 35. Laser compartment 26. Locking bolt 36. Laser holder 27. Support foot 37. Guide bar JCB-MS-254SB-L Instruction & User Manual...
-
Page 12: Technical Data
Technical changes reserved! WARNING! The workpiece must have a minimum height of 1/8” (3 mm) and a minimum width of 0.4” (10 mm). Maake sure that the workpiece is always secured with the clamping device. JCB-MS-254SB-L Instruction & User Manual... -
Page 13: Vibration And Noise Information
In this regard, all the operational cycle phases must be taken into consideration (such as the times when the tool is switched off or running idle). JCB-MS-254SB-L Instruction & User Manual... -
Page 14: Operating Instructions
It is also imperative to observe the accident prevention regulations in force in your area. The same applies for the general rules of health and safety at work. JCB-MS-254SB-L Instruction & User Manual... -
Page 15: Before Starting The Equipment
Do not use the tool if the switch does not allow you to switch from the ON state to the OFF state. JCB-MS-254SB-L Instruction & User Manual... -
Page 16: Assembly And Operation
(15) as shown in Figure 4 and fasten with the screw (9). • It is possible to tilt the machine head (4) a max. 45° to the left by loosening the locking screw (22). JCB-MS-254SB-L Instruction & User Manual... -
Page 17: Precision Adjustment Of The Stop For Crosscut
Keep all visitors at a safe distance from the mitre saw. Make sure bystanders are clear of the saw and workpiece. Don’t force the saw. It will do the job better and safer at its designed rate. JCB-MS-254SB-L Instruction & User Manual... -
Page 18: Cross Cut 90° And Turntable
(16a) and the saw blade (6). light counter pressure. • Tighten the set screw (16b) again. JCB-MS-254SB-L Instruction & User Manual... -
Page 19: Cross Cut 90° And Turntable 0
• 45° - position angle stop between the saw The crosscut saw can be used to make blade (6) and turn table (14). crosscuts of 0° -45° to the left and 0° -45° to the right in relation to the stop rail. JCB-MS-254SB-L Instruction & User Manual... - Page 20 (1) to angle the machine head (4) to the left, until the pointer (19) indicates the desired angle measurement on the scale (18). • Re-tighten the locking screw (22). • Cut as described in section “Cross cut 90° and turn table 0°”. JCB-MS-254SB-L Instruction & User Manual...
-
Page 21: Bevel Cut 0°- 45° And Turntable
0°- 45° in relation to the work face and, at the same time, 0° - 45° to the left or 0° - 45° to the right in relation to the stop rail (double mitre cut). JCB-MS-254SB-L Instruction & User Manual... -
Page 22: Changing The Saw Blade
(30) and inner flange (32). • Please reverse operation according to the above method when you assemble the saw blade. ATTENTION: Match the direction arrow on the blade with the direction arrow on the Fig.17 upper guard. JCB-MS-254SB-L Instruction & User Manual... -
Page 23: Maintenance And Electrical Connection
• connection conditions. This means that WARNING! Failure to unplug mitre use of the product at any freely selectable saws could result in accidental starting connection point is not allowed. causing possible serious personal injury. JCB-MS-254SB-L Instruction & User Manual... -
Page 24: Transport
Electrical connection cables must comply with the applicable VDE and DIN provisions. Only use connection cables with the marking “H07RN-F”. The printing of the type designation on the connection cable is mandatory. JCB-MS-254SB-L Instruction & User Manual... -
Page 25: Storage
You can obtain information on collection points for waste equipment from your municipal administration, public waste disposal authority, an authorised body for the disposal of waste electrical and electronic equipment or your waste disposal company. JCB-MS-254SB-L Instruction & User Manual... -
Page 26: Warranty Statement
In the unlikely event your JCB Power Tool is subject to a manufacturing fault within the warranty period, please contact the seller/retailer where the item was purchased. JCB Power Tools used for Hire Fleets or as part of B2B and Service Contracts are not covered by these terms and conditions. - Page 27 JCB-MS-254SB-L Instruction & User Manual...
-
Page 28: General Certificate Of Conformity
IEC 62841-1:2015+AC:15. IEC 62841-3-9:2016. IEC 60825-1:2014 (Laser) IEC 55014-1:2017. IEC 55014-2:2015. IEC 61000-3-2:2014. IEC 61000-3-2:2013. IDENTIFICATION DETAILS OF IMPORTER/US DOMESTIC MANUFACTURER CERTIFYING PRODUCT COMPLIANCE: Name: JCB Tools (Yellow and Black Tools Limited) Address: 55 Romsey Industrial Estate Romsey, SO51 0HR Tel no: +44 1794 834250... - Page 29 JCB-MS-254SB-L Instruction & User Manual...
