ULTRA PORTABLE PROJECTOR
VP150X
USER'S GUIDE
Thank you for purchasing Benq Ultra Portable Projector.
Please read this user's guide to ensure correct use of the device. Save this user's guide for future reference.
OUTLINE
This Ultra Portable Projector can display various computer
signals and NTSC/PAL/SECAM video signals.
FEATURES
1. High Brightness
2. High Resolution
3. Easy to Set Up
4. Compact Size, Light Weight for Portability
5. RGB Output Terminal
6. Mouse Emulation
7. Auto-Adjustment Function (i - key)
8. USB Communication
Advertisement
Table of Contents
Related Manuals for BenQ Professional VP150X
Summary of Contents for BenQ Professional VP150X
- Page 1 ULTRA PORTABLE PROJECTOR VP150X USER’S GUIDE Thank you for purchasing Benq Ultra Portable Projector. Please read this user’s guide to ensure correct use of the device. Save this user’s guide for future reference. OUTLINE This Ultra Portable Projector can display various computer signals and NTSC/PAL/SECAM video signals.
-
Page 2: Projector Information
Furthermore, Benq Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of Benq Corporation to notify any person of such revision or changes. -
Page 3: Safety Instructions
Do not operate lamps beyond the rated lamp life. Excessive operation of lamps beyond rated life could cause them to explode in rare occasions. Power is still available when the projector is in the standby mode. Never replace lamp assembly or any electronic components unless the projector is unplugged. -
Page 4: Table Of Contents
Connect the Projector to Computer ... 6 Connect the Projector to Notebook ... 6 Connect the Projector to Macintosh... 7 Connect the Projector to Power Book ... 7 Connect to Video/ S-Video ... 7 OPERATION ... 8 Turn On/Off Procedure ... 8 ... -
Page 5: Introduction
(RGB) required for color reproduction on LCD Panel. C. Portability This projector has a sophisticated shape, like that of an attaché case, with a retractable carrying handle that is extremely compact and lightweight. It helps you make powerful presentations wherever you go with its 8-pound weight and A4 size. -
Page 6: Description
Description FRONT Projecton Lens Figure 1. Front view RIGHT Figure 2. Right view BOTTOM Figure 3. Bottom view English Ventilation Hole Lamp cover... -
Page 7: Installation
Installation Image Size Adjustment This projector is basically designed to project on a flat projection surface. This projector can be focused from 1m–12.3m. Refer to Figure. 4 to adjust the screen size. Lens center Projection distance Figure 4. Positioning Projection distance... -
Page 8: Moving The Projector
Caution The carrying bag is supplied to protect the projector from dust and scratches on the surface of the cabinet. It is not designed to protect the projector from external shock. Do not transport the projector in an unsuitable transport case by using a courier or transport service. This may cause damage to the projector. -
Page 9: Accessories
Accessories Please check and ensure your box contains everything listed below. Contact your dealer, if any pieces are missing,. Please save the original box and packing materials in case you ever need to ship the unit. User’s Guide Batteries Figure 7. Accessories Remote Controle Mac Adapter VGA Cable... -
Page 10: Connection
CONNECTION Connect the Projector to Computer Figure 8. Connect to PC Connect the Projector to Notebook Figure 9. Connect to notebook English Mouse Cable for PS/2 Port (Supplied) ADB Port Input Computer Input Computer output VGA Cable (supplied) Mouse Cable... -
Page 11: Connect The Projector To Macintosh
Connect the Projector to Macintosh Computer output VGA/MAC Adapter (Supplied) Figure 10. Connect to Macintosh Connect the Projector to Power Book Figure 11. Connect to Power Book Connect to Video/ S-Video Figure 12. Connect to Video, S-Video Mouse Cable for PS/2 Port... -
Page 12: Operation
1 minutes to cool the lamp. After the fans stop, the LED will turn to a solid orange light. *Lamp Protection Procedure: If you try to turn on the lamp again while the LED is blinking, the projector will ignore the command until it is cooled down for one minute. -
Page 13: Remote Control
MAIN UNIT Menu To call the OSD menu. To enter sub pages. To select items. To navigate through sub pages or to increase/decrease the scale bar number. Exit To exit from the current page or OSD menu, and save setting changes. To show lamp hour messages. - Page 14 The remote control allows you to operate the function keys on the projector and to emulate mouse function when the projector is connected to a computer. Main Unit Standby/On To turn the projection lamp on and off. Freeze Pressing this button displays a still (frozen) picture.
-
Page 15: Usage And Replacement Of Lamp
Remote Control Range The remote sensors are located on the back of the unit. It can function in a range 50 degrees horizontal and 30 degrees vertical relative to a line that is a right angle to the remote sensor. The distance between the remote control and remote sensor must be shorter than four meters (13 feet). -
Page 16: Lamp Replacement
Caution The lamp indicator will light up when the lamp becomes too hot. Turn off the power and let the projector cool down for 45 minutes, then turn it on again. If the indicator is still on, contact your dealer. -
Page 17: Lamp Replacement Procedure
Carry out the following operation within 10 minutes of powering on after a new lamp is installed. Step 2 Press Exit on the projector for 3 seconds or Exit on the remote control for 3 seconds and display the total lamp usage time. -
Page 18: Osd
Main OSD Menu Press Menu and the main OSD menu structure will appear as shown at right (Figure 18). Whenever AV connector is attached, 4 sub-pages appear in the menu: Display page, Image page, Control page and Source page. Press the " " or " "... -
Page 19: B Image Page
Only available when the input signal is PC. Auto Resize When Auto Resize is on, the projector determines the best fit of the image to the screen. H. Phase If flickers occur on the projected image, users may try to adjust the H. Phase manually. -
Page 20: C Control Page
There are five items on this page: Source, Volume, Treble, Bass, and Mute. *The sequence of input signal detection: a. PC b. Video c. S-Video *When selecting input sources, the projector will detect the selected input simultaneously, and the OSD menu will still exist on the screen. English Figure 23. -
Page 21: Other Correspondent And Remote Functions Messages
Return. Press this button to generate the laser beam. If users connect the PS2 (ADB) mouse cable on the projector with the PC/Notebook (Macintosh/ Powerbook) mouse port, the disk pad will be able to function as a PC/Notebook (Macintosh/ Powerbook) mouse. -
Page 22: Maintenance And Troubleshooting
Plug the power cord into the AC Inlet. Plug the power cord into the power Inlet. Wait for 2 minutes after the projector is turned off before turning the projector back on. Check if you select the proper input source. -
Page 23: Specifications
SPECIFICATIONS Optical LCD Panel Lens Lamp Image size Projection Distance Electrical Inputs RGB Video Color Reproduction Power Requirement Mechanical Dimensions Operational Temperature projector Remote control Preset Display Resolution Table Resolution 640x350 640x400 640x400 720x400 640x480 640x480 640x480 640x480 800x600 800x600... - Page 24 English...
